Test Date: 2016-09-19 17:13
Analysis date: 2016-09-19 18:55
Analysis date: 2016-09-19 18:55
M2319 XRayHRQualification
Summary
| Module | Module | M2319 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 16 | |
| BumpBondingDefects | Bump Bonding Defects | 16 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.18 | % |
| Noise | Mean Noise | 161 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.87 | 99.19 | 0.4 | 21.8 | 66.4 | 1 | 0/0 | 0 | 1971 | 154 | 0 |
|
Chip 1
|
A
|
4 | 0 | 99.84 | 98.93 | 0.72 | 25.2 | 76.2 | 4 | 0/0 | 0 | 1998 | 159 | 0 |
|
Chip 2
|
A
|
2 | 0 | 99.83 | 98.98 | 0.42 | 21.8 | 67.2 | 2 | 0/0 | 0 | 1963 | 160 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.89 | 99.29 | 0.52 | 37.8 | 111.7 | 1 | 0/0 | 0 | 2086 | 164 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.88 | 99.31 | 0.54 | 39.5 | 117.5 | 1 | 0/0 | 0 | 2098 | 156 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.34 | 0.56 | 49.9 | 144.3 | 0 | 0/0 | 0 | 2148 | 169 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.88 | 99.27 | 0.69 | 44.3 | 129.6 | 1 | 0/0 | 0 | 2096 | 158 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.22 | 0.78 | 46.2 | 135.8 | 0 | 0/0 | 0 | 2127 | 150 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.86 | 99.31 | 0.5 | 43.1 | 127.7 | 1 | 0/0 | 0 | 2096 | 161 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.88 | 99.31 | 0.56 | 42.9 | 125.8 | 1 | 0/0 | 0 | 2099 | 165 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.87 | 99.31 | 0.57 | 44.0 | 129.1 | 1 | 0/0 | 0 | 2102 | 159 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.85 | 98.99 | 0.68 | 34.1 | 102.5 | 0 | 0/0 | 0 | 2042 | 162 | 0 |
|
Chip 12
|
A
|
3 | 0 | 99.87 | 99.28 | 0.59 | 32.8 | 98.6 | 3 | 0/0 | 0 | 2032 | 158 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.28 | 0.41 | 20.7 | 63.3 | 0 | 0/0 | 0 | 1959 | 169 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 98.97 | 0.66 | 22.9 | 69.3 | 0 | 0/0 | 0 | 1999 | 165 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 98.90 | 0.47 | 21.3 | 64.5 | 0 | 0/0 | 0 | 1954 | 166 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-19 | |
| TestTime | Test Time | 17:13 | |
| TestDuration | Duration | 1:29:9 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
