Test Date: 2016-09-20 10:14
Analysis date: 2016-09-20 13:17
Analysis date: 2016-09-20 13:17
M2317 XRayHRQualification
Summary
| Module | Module | M2317 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 10 | |
| BumpBondingDefects | Bump Bonding Defects | 5 | |
| NoisyPixels | Noisy Pixels | 3 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.24 | % |
| Noise | Mean Noise | 164 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.89 | 99.31 | 0.45 | 30.8 | 93.6 | 2 | 0/0 | 0 | 2007 | 174 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.02 | 0.49 | 31.2 | 95.3 | 0 | 0/0 | 0 | 2014 | 171 | 0 |
|
Chip 2
|
A
|
2 | 0 | 99.85 | 99.24 | 1.52 | 27.0 | 83.9 | 0 | 0/0 | 0 | 1964 | 161 | 1 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.26 | 0.78 | 43.6 | 131.7 | 0 | 0/0 | 0 | 2104 | 158 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.32 | 0.76 | 53.7 | 160.6 | 0 | 0/0 | 0 | 2174 | 178 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 99.36 | 0.74 | 67.3 | 196.7 | 0 | 0/0 | 0 | 2238 | 177 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.29 | 0.91 | 60.2 | 177.4 | 0 | 0/0 | 0 | 2196 | 164 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.27 | 1.56 | 62.2 | 183.5 | 0 | 0/0 | 0 | 2231 | 163 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.31 | 0.59 | 59.2 | 174.5 | 0 | 0/0 | 0 | 2182 | 161 | 0 |
|
Chip 9
|
A
|
2 | 0 | 99.87 | 99.31 | 0.49 | 61.0 | 178.0 | 2 | 0/0 | 0 | 2222 | 166 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.27 | 0.57 | 62.0 | 179.6 | 0 | 0/0 | 0 | 2214 | 158 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.86 | 99.30 | 0.66 | 46.3 | 138.7 | 1 | 0/0 | 0 | 2130 | 153 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.84 | 99.15 | 0.72 | 39.0 | 119.2 | 0 | 0/0 | 0 | 2066 | 146 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.33 | 0.6 | 26.5 | 82.3 | 0 | 0/0 | 0 | 1992 | 163 | 0 |
|
Chip 14
|
A
|
2 | 0 | 99.87 | 99.21 | 0.63 | 32.2 | 97.9 | 0 | 0/0 | 0 | 1952 | 175 | 2 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 98.93 | 0.54 | 27.3 | 83.5 | 0 | 0/0 | 0 | 1988 | 155 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-20 | |
| TestTime | Test Time | 10:14 | |
| TestDuration | Duration | 1:15:45 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 18 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 2 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 1 | |
| message_tokenchain_count | Token Chain Length | 2 | |
| message_readback_count | Readback start marker | 1 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
