Test Date: 2016-09-19 15:21
Analysis date: 2016-09-19 17:31
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
48.7838125 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
48.7838125 |
|
| medianSlope |
median Slope |
49.041 |
|
| minSlope |
min Slope |
44.299 |
|
| maxSlope |
max Slope |
51.117 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-16.658 |
|
| medianOffset |
median Offset |
18.813 |
|
| minOffset |
min Offset |
-154.726 |
|
| maxOffset |
max Offset |
89.99 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
4.9809375 |
|
| medianchi2 |
median chi2 |
2.093 |
|
| minchi2 |
min chi2 |
0.053 |
|
| maxchi2 |
max chi2 |
25.411 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
50.2 e- / Vcal
|
0.2 e- / Vcal
|
-68.0 e-
|
19.5 e-
|
|
1
|
49.4 e- / Vcal
|
0.2 e- / Vcal
|
24.1 e-
|
20.6 e-
|
|
2
|
48.5 e- / Vcal
|
0.1 e- / Vcal
|
-97.5 e-
|
11.2 e-
|
|
3
|
48.6 e- / Vcal
|
0.1 e- / Vcal
|
19.5 e-
|
7.0 e-
|
|
4
|
51.1 e- / Vcal
|
0.1 e- / Vcal
|
-104.9 e-
|
6.8 e-
|
|
5
|
48.9 e- / Vcal
|
0.1 e- / Vcal
|
78.1 e-
|
5.7 e-
|
|
6
|
45.1 e- / Vcal
|
0.1 e- / Vcal
|
18.1 e-
|
5.9 e-
|
|
7
|
48.7 e- / Vcal
|
0.1 e- / Vcal
|
90.0 e-
|
16.6 e-
|
|
8
|
49.6 e- / Vcal
|
0.1 e- / Vcal
|
-104.7 e-
|
6.6 e-
|
|
9
|
48.9 e- / Vcal
|
0.1 e- / Vcal
|
22.5 e-
|
6.5 e-
|
|
10
|
51.0 e- / Vcal
|
0.1 e- / Vcal
|
-41.5 e-
|
5.9 e-
|
|
11
|
49.5 e- / Vcal
|
0.2 e- / Vcal
|
54.1 e-
|
18.2 e-
|
|
12
|
49.2 e- / Vcal
|
0.1 e- / Vcal
|
-154.7 e-
|
17.4 e-
|
|
13
|
44.3 e- / Vcal
|
0.1 e- / Vcal
|
-75.4 e-
|
19.2 e-
|
|
14
|
49.2 e- / Vcal
|
0.1 e- / Vcal
|
35.1 e-
|
8.0 e-
|
|
15
|
48.3 e- / Vcal
|
0.2 e- / Vcal
|
38.6 e-
|
18.1 e-
|
|
Average
|
48.8 e- / Vcal
|
|
-16.7 e-
|
|
|
Median
|
98.3 e- / Vcal
|
|
-14.7 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
