Test Date: 2016-09-19 15:21
Analysis date: 2016-09-19 17:31
Chip 4
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 50/150 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 50/150 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 50/150 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 50/150 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 50/150 0/0
Efficiency Efficiency 50/120 99.87/99.29
EfficiencyFit Efficiency Fit chi2/ndf: 0.67, # points: 110
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 50/150 A/A
HitMapGrade Hit Map Grade 50/150 (A)/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 50/150 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 50/150 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C4
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.67
NumberFitPoints # fit points 110
p0 p0 99.91
p1 p1 3.58e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.87
InterpolatedEfficiency120 Interpol. Efficiency 120 99.29
Efficiency Map 50: C4
Efficiency Map 75: C4
Efficiency Map 100: C4
Efficiency Map 125: C4
Efficiency Map 150: C4
Efficiency Map 200: C4
Efficiency Map 250: C4
Efficiency Distr. 50: C4
Plot
N N 4160
mu μ 99.88
sigma σ 0.50
Efficiency Distr. 75: C4
Plot
N N 4160
mu μ 99.78
sigma σ 0.67
Efficiency Distr. 100: C4
Plot
N N 4160
mu μ 99.56
sigma σ 1.00
Efficiency Distr. 125: C4
Plot
N N 4160
mu μ 99.26
sigma σ 1.47
Efficiency Distr. 150: C4
Plot
N N 4160
mu μ 98.78
sigma σ 2.02
Efficiency Distr. 200: C4
Plot
N N 4160
mu μ 97.02
sigma σ 4.07
Efficiency Distr. 250: C4
Plot
N N 4160
mu μ 94.52
sigma σ 6.54
Background Map 50: C4
Plot
RealHitrate Real Hitrate 43.62 MHz/cm2
Background Map 75: C4
Plot
RealHitrate Real Hitrate 64.59 MHz/cm2
Background Map 100: C4
Plot
RealHitrate Real Hitrate 89.04 MHz/cm2
Background Map 125: C4
Plot
RealHitrate Real Hitrate 108.55 MHz/cm2
Background Map 150: C4
Plot
RealHitrate Real Hitrate 129.86 MHz/cm2
Background Map 200: C4
Plot
RealHitrate Real Hitrate 177.13 MHz/cm2
Background Map 250: C4
Plot
RealHitrate Real Hitrate 217.94 MHz/cm2
Retrim Hot Pix 150: C4
Retrim Hot Pix 50: C4
Masked Hot Pixels 50: C4
Masked Hot Pixels 150: C4
Hit Map 50: C4
Plot
RealHitrate Real Hitrate 42.36 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 50: C4
Hit Map 150: C4
Plot
RealHitrate Real Hitrate 126.82 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 150: C4
Col. Read. Unif. 50: C4
Plot
N N 5879811
mu μ 131740
sigma σ 47495.89
Col. Read. Unif. 150: C4
Plot
N N 17677187
mu μ 394399
sigma σ 132058.98
Read. Unif. over Time 50: C4
Plot
N N 6850494
mu μ 6948
sigma_th σ_th 83.35
Time unif. distribution 50: C4
Plot
chi2/ndf chi2/ndf 1.96
sigma σ 88.34
sigma_th σ_th 83.35
expectation Red curve (expected) Poisson
Read. Unif. over Time 150: C4
Plot
N N 20508746
mu μ 20800
sigma_th σ_th 144.22
Time unif. distribution 150: C4
Plot
chi2/ndf chi2/ndf 8.82
sigma σ 167.04
sigma_th σ_th 144.23
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C4
Col. Uniformity per Event: C4 50
Plot
mu μ 27.79
sigma fit error of μ 2.25
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C4 150
Plot
mu μ 27.74
sigma fit error of μ 2.25
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C4 100
Plot
N N 4160
mu μ 154.45
sigma RMS 14.68
threshold thr 2099.70
fit fit Gaussian
fit_peak μ fit 154.00
fit_sigma σ fit 13.83
MeasuredHitrate Measured hitrate: 89.1
Alive Map: C4
DC Efficiency Distribution: C4
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.87
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.28
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C4
