Test Date: 2016-09-19 15:21
Analysis date: 2016-09-19 17:31
Chip 13
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 50/150 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 50/150 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 50/150 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 50/150 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 50/150 0/0
Efficiency Efficiency 50/120 99.86/99.26
EfficiencyFit Efficiency Fit chi2/ndf: 0.55, # points: 96
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 50/150 A/A
HitMapGrade Hit Map Grade 50/150 (A)/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 50/150 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 50/150 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C13
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.55
NumberFitPoints # fit points 96
p0 p0 99.91
p1 p1 3.74e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.86
InterpolatedEfficiency120 Interpol. Efficiency 120 99.26
Efficiency Map 50: C13
Efficiency Map 75: C13
Efficiency Map 100: C13
Efficiency Map 125: C13
Efficiency Map 150: C13
Efficiency Map 200: C13
Efficiency Map 250: C13
Efficiency Distr. 50: C13
Plot
N N 4160
mu μ 99.92
sigma σ 0.40
Efficiency Distr. 75: C13
Plot
N N 4160
mu μ 99.84
sigma σ 0.62
Efficiency Distr. 100: C13
Plot
N N 4160
mu μ 99.66
sigma σ 1.01
Efficiency Distr. 125: C13
Plot
N N 4160
mu μ 99.46
sigma σ 1.52
Efficiency Distr. 150: C13
Plot
N N 4160
mu μ 99.12
sigma σ 2.18
Efficiency Distr. 200: C13
Plot
N N 4160
mu μ 97.90
sigma σ 4.78
Efficiency Distr. 250: C13
Plot
N N 4160
mu μ 96.24
sigma σ 7.87
Background Map 50: C13
Plot
RealHitrate Real Hitrate 29.75 MHz/cm2
Background Map 75: C13
Plot
RealHitrate Real Hitrate 43.93 MHz/cm2
Background Map 100: C13
Plot
RealHitrate Real Hitrate 61.07 MHz/cm2
Background Map 125: C13
Plot
RealHitrate Real Hitrate 74.63 MHz/cm2
Background Map 150: C13
Plot
RealHitrate Real Hitrate 89.73 MHz/cm2
Background Map 200: C13
Plot
RealHitrate Real Hitrate 122.88 MHz/cm2
Background Map 250: C13
Plot
RealHitrate Real Hitrate 153.29 MHz/cm2
Retrim Hot Pix 150: C13
Retrim Hot Pix 50: C13
Masked Hot Pixels 50: C13
Masked Hot Pixels 150: C13
Hit Map 50: C13
Plot
RealHitrate Real Hitrate 28.99 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 50: C13
Hit Map 150: C13
Plot
RealHitrate Real Hitrate 88.96 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 150: C13
Col. Read. Unif. 50: C13
Plot
N N 3904632
mu μ 90147
sigma σ 68308.41
Col. Read. Unif. 150: C13
Plot
N N 12069315
mu μ 276658
sigma σ 190302.62
Read. Unif. over Time 50: C13
Plot
N N 4687649
mu μ 4754
sigma_th σ_th 68.95
Time unif. distribution 50: C13
Plot
chi2/ndf chi2/ndf 1.53
sigma σ 71.78
sigma_th σ_th 68.95
expectation Red curve (expected) Poisson
Read. Unif. over Time 150: C13
Plot
N N 14386200
mu μ 14590
sigma_th σ_th 120.79
Time unif. distribution 150: C13
Plot
chi2/ndf chi2/ndf 2.29
sigma σ 128.01
sigma_th σ_th 120.80
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C13
Col. Uniformity per Event: C13 50
Plot
mu μ 20.93
sigma fit error of μ 2.47
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C13 150
Plot
mu μ 21.50
sigma fit error of μ 2.45
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C13 100
Plot
N N 4160
mu μ 173.42
sigma RMS 15.91
threshold thr 2003.82
fit fit Gaussian
fit_peak μ fit 172.59
fit_sigma σ fit 14.64
MeasuredHitrate Measured hitrate: 61.0
Alive Map: C13
DC Efficiency Distribution: C13
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.88
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.17
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C13
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
