Test Date: 2016-09-19 15:21
Analysis date: 2016-09-19 17:31
Chip 12
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 50/150 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 50/150 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 50/150 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 50/150 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 50/150 0/0
Efficiency Efficiency 50/120 99.88/99.29
EfficiencyFit Efficiency Fit chi2/ndf: 0.63, # points: 110
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 50/150 A/A
HitMapGrade Hit Map Grade 50/150 (A)/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 50/150 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 50/150 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C12
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.63
NumberFitPoints # fit points 110
p0 p0 99.92
p1 p1 3.65e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.88
InterpolatedEfficiency120 Interpol. Efficiency 120 99.29
Efficiency Map 50: C12
Efficiency Map 75: C12
Efficiency Map 100: C12
Efficiency Map 125: C12
Efficiency Map 150: C12
Efficiency Map 200: C12
Efficiency Map 250: C12
Efficiency Distr. 50: C12
Plot
N N 4160
mu μ 99.89
sigma σ 0.48
Efficiency Distr. 75: C12
Plot
N N 4160
mu μ 99.76
sigma σ 0.70
Efficiency Distr. 100: C12
Plot
N N 4160
mu μ 99.46
sigma σ 1.14
Efficiency Distr. 125: C12
Plot
N N 4160
mu μ 99.15
sigma σ 1.53
Efficiency Distr. 150: C12
Plot
N N 4160
mu μ 98.62
sigma σ 2.04
Efficiency Distr. 200: C12
Plot
N N 4160
mu μ 96.53
sigma σ 4.05
Efficiency Distr. 250: C12
Plot
N N 4160
mu μ 93.54
sigma σ 6.45
Background Map 50: C12
Plot
RealHitrate Real Hitrate 47.38 MHz/cm2
Background Map 75: C12
Plot
RealHitrate Real Hitrate 69.64 MHz/cm2
Background Map 100: C12
Plot
RealHitrate Real Hitrate 95.29 MHz/cm2
Background Map 125: C12
Plot
RealHitrate Real Hitrate 116.66 MHz/cm2
Background Map 150: C12
Plot
RealHitrate Real Hitrate 138.48 MHz/cm2
Background Map 200: C12
Plot
RealHitrate Real Hitrate 188.58 MHz/cm2
Background Map 250: C12
Plot
RealHitrate Real Hitrate 234.47 MHz/cm2
Retrim Hot Pix 150: C12
Retrim Hot Pix 50: C12
Masked Hot Pixels 50: C12
Masked Hot Pixels 150: C12
Hit Map 50: C12
Plot
RealHitrate Real Hitrate 45.86 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 50: C12
Hit Map 150: C12
Plot
RealHitrate Real Hitrate 137.12 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 150: C12
Col. Read. Unif. 50: C12
Plot
N N 6442486
mu μ 142629
sigma σ 44516.31
Col. Read. Unif. 150: C12
Plot
N N 19317178
mu μ 426408
sigma σ 124102.21
Read. Unif. over Time 50: C12
Plot
N N 7416722
mu μ 7522
sigma_th σ_th 86.73
Time unif. distribution 50: C12
Plot
chi2/ndf chi2/ndf 0.94
sigma σ 89.92
sigma_th σ_th 86.73
expectation Red curve (expected) Poisson
Read. Unif. over Time 150: C12
Plot
N N 22173230
mu μ 22488
sigma_th σ_th 149.96
Time unif. distribution 150: C12
Plot
chi2/ndf chi2/ndf 6.33
sigma σ 170.35
sigma_th σ_th 149.97
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C12
Col. Uniformity per Event: C12 50
Plot
mu μ 26.89
sigma fit error of μ 2.22
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C12 150
Plot
mu μ 26.77
sigma fit error of μ 2.21
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C12 100
Plot
N N 4160
mu μ 165.98
sigma RMS 15.82
threshold thr 2086.25
fit fit Gaussian
fit_peak μ fit 165.35
fit_sigma σ fit 14.97
MeasuredHitrate Measured hitrate: 95.6
Alive Map: C12
DC Efficiency Distribution: C12
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.88
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.29
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C12
