Test Date: 2016-09-07 11:25
Analysis date: 2016-09-07 13:27
Analysis date: 2016-09-07 13:27
M2308 XRayHRQualification
Summary
| Module | Module | M2308 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 4 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.23 | % |
| Noise | Mean Noise | 174 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.85 | 99.09 | 0.61 | 28.8 | 86.0 | 0 | 0/0 | 0 | 1981 | 164 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 98.94 | 0.58 | 33.0 | 98.6 | 0 | 0/0 | 0 | 2010 | 181 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.12 | 0.43 | 29.8 | 90.4 | 0 | 0/0 | 0 | 1979 | 178 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.85 | 99.29 | 0.67 | 56.8 | 165.9 | 0 | 0/0 | 0 | 2197 | 172 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.85 | 99.31 | 0.78 | 53.6 | 155.7 | 0 | 0/0 | 0 | 2151 | 166 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.85 | 99.30 | 0.79 | 67.5 | 193.0 | 0 | 0/0 | 0 | 2229 | 164 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.33 | 0.38 | 66.7 | 193.6 | 0 | 0/0 | 0 | 2228 | 169 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.84 | 99.34 | 0.43 | 74.6 | 217.1 | 1 | 0/0 | 0 | 2287 | 182 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.33 | 0.43 | 76.2 | 222.4 | 0 | 0/0 | 0 | 2302 | 198 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.33 | 0.44 | 68.6 | 199.4 | 0 | 0/0 | 0 | 2247 | 166 | 0 |
|
Chip 10
|
A
|
2 | 0 | 99.86 | 99.34 | 0.55 | 71.1 | 203.7 | 2 | 0/0 | 0 | 2250 | 176 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.85 | 99.28 | 0.61 | 61.8 | 181.3 | 0 | 0/0 | 0 | 2223 | 187 | 0 |
|
Chip 12
|
A
|
2 | 0 | 99.86 | 99.19 | 2.07 | 55.3 | 161.3 | 1 | 0/0 | 0 | 2159 | 169 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.18 | 0.46 | 30.9 | 93.2 | 0 | 0/0 | 0 | 2014 | 170 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.07 | 0.88 | 35.6 | 106.1 | 0 | 0/0 | 0 | 2032 | 173 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 99.24 | 1.68 | 34.0 | 99.9 | 0 | 0/0 | 0 | 2052 | 174 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-07 | |
| TestTime | Test Time | 11:25 | |
| TestDuration | Duration | 1:34:29 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
