Test Date: 2016-09-05 15:24
Analysis date: 2016-09-05 16:58
Analysis date: 2016-09-05 16:58
Chip 9
Grading
| ROCGrade | Final ROC Grade | A | |
| NumberOfHotPixels | # Hot Pixels 50/150 | 0/0 | |
| NumberOfNonUniformColumns | # Non-Uniform Columns 50/150 | 0 | |
| NumberOfNonUniformEvents | # Non-Uniform ROC Events 50/150 | 0/0 | |
| NumberOfNonUniformColumnEvents | # Non-Uniform Col. Events 50/150 | 0/0 | |
| BadDoubleColumns | # Bad Double Columns | 0 | |
| BumpBondingDefects | # Bump Bonding Defects 50/150 | 0/0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.27 | |
| EfficiencyFit | Efficiency Fit | chi2/ndf: 0.47, # points: 88 | |
| EfficiencyGrade | Efficiency Grade 50/120 | (A)/A | |
| BadDoubleColumnsGrade | Bad DC Grade | A | |
| HotPixelsGrade | Hot Pixels Grade 50/150 | A/A | |
| HitMapGrade | Hit Map Grade 50/150 | (A)/A | |
| ReadoutUniformityOverTimeGrade | ROC Read. Unif. Grade 50/150 | A/A | |
| ColumnReadoutUniformityOverTimeGrade | Column Read. Unif. Grade 50/150 | A/A | |
| ColumnUniformityGrade | Column Uniformity Grade | A | |
| NoiseGrade | Noise Grade | A |
Efficiency Interpolation: C9
| fitfunction | Fit | [0]-[1]*x^3 | |
| BadDoubleColumns | # Bad DCs (excluded from fit) | 0 | |
| Chi2NDF | chi2/ndf | 0.47 | |
| NumberFitPoints | # fit points | 88 | |
| p0 | p0 | 99.90 | |
| p1 | p1 | 3.65e-07 | |
| InterpolatedEfficiency50 | Interpol. Efficiency 50 | 99.86 | |
| InterpolatedEfficiency120 | Interpol. Efficiency 120 | 99.27 |
Hit Map 50: C9
| RealHitrate | Real Hitrate | 59.10 | MHz/cm2 |
| NumberOfDefectivePixels | # Defective Pixels | 0 |
Hit Map 150: C9
| RealHitrate | Real Hitrate | 174.16 | MHz/cm2 |
| NumberOfDefectivePixels | # Defective Pixels | 0 |
Col. Read. Unif. 50: C9
Col. Read. Unif. 150: C9
Read. Unif. over Time 50: C9
Time unif. distribution 50: C9
| chi2/ndf | chi2/ndf | 1.69 | |
| sigma | σ | 105.09 | |
| sigma_th | σ_th | 98.46 | |
| expectation | Red curve (expected) | Poisson |
Read. Unif. over Time 150: C9
Time unif. distribution 150: C9
| chi2/ndf | chi2/ndf | 13.35 | |
| sigma | σ | 198.37 | |
| sigma_th | σ_th | 169.02 | |
| expectation | Red curve (expected) | Poisson |
Col. Uniformity per Event: C9 50
| mu | μ | 26.21 | |
| sigma | fit error of μ | 2.26 | |
| NumberOfNonUniformColumnEvents | Non uniform 10.000 event bins | 0 |
Col. Uniformity per Event: C9 150
| mu | μ | 26.01 | |
| sigma | fit error of μ | 2.26 | |
| NumberOfNonUniformColumnEvents | Non uniform 10.000 event bins | 0 |
S-Curve widths: Noise (e^{-}) C9 100
| N | N | 4160 | |
| mu | μ | 155.50 | |
| sigma | RMS | 15.48 | |
| threshold | thr | 2170.79 | |
| fit | fit | Gaussian | |
| fit_peak | μ fit | 155.02 | |
| fit_sigma | σ fit | 14.66 | |
| MeasuredHitrate | Measured hitrate: | 121.2 |
DC Efficiency Distribution: C9
| MeanEfficiency_50 | Mean Efficiency 50 MHz/cm2 | 99.85 | |
| MeanEfficiency_120 | Mean Efficiency 120 MHz/cm2 | 99.28 | |
| NBadDoubleColumns | Bad Double Columns | 0 |
