Test Date: 2016-09-05 15:24
Analysis date: 2016-09-05 16:58
Chip 13
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 50/150 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 50/150 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 50/150 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 50/150 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 50/150 0/0
Efficiency Efficiency 50/120 99.86/99.29
EfficiencyFit Efficiency Fit chi2/ndf: 0.53, # points: 98
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 50/150 A/A
HitMapGrade Hit Map Grade 50/150 (A)/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 50/150 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 50/150 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C13
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.53
NumberFitPoints # fit points 98
p0 p0 99.90
p1 p1 3.55e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.86
InterpolatedEfficiency120 Interpol. Efficiency 120 99.29
Efficiency Map 50: C13
Efficiency Map 75: C13
Efficiency Map 100: C13
Efficiency Map 125: C13
Efficiency Map 150: C13
Efficiency Map 200: C13
Efficiency Map 250: C13
Efficiency Distr. 50: C13
Plot
N N 4160
mu μ 99.93
sigma σ 0.38
Efficiency Distr. 75: C13
Plot
N N 4160
mu μ 99.86
sigma σ 0.56
Efficiency Distr. 100: C13
Plot
N N 4160
mu μ 99.72
sigma σ 0.85
Efficiency Distr. 125: C13
Plot
N N 4160
mu μ 99.57
sigma σ 1.20
Efficiency Distr. 150: C13
Plot
N N 4160
mu μ 99.31
sigma σ 1.70
Efficiency Distr. 200: C13
Plot
N N 4160
mu μ 98.38
sigma σ 3.60
Efficiency Distr. 250: C13
Plot
N N 4160
mu μ 96.97
sigma σ 6.18
Background Map 50: C13
Plot
RealHitrate Real Hitrate 28.91 MHz/cm2
Background Map 75: C13
Plot
RealHitrate Real Hitrate 42.75 MHz/cm2
Background Map 100: C13
Plot
RealHitrate Real Hitrate 59.47 MHz/cm2
Background Map 125: C13
Plot
RealHitrate Real Hitrate 72.44 MHz/cm2
Background Map 150: C13
Plot
RealHitrate Real Hitrate 86.52 MHz/cm2
Background Map 200: C13
Plot
RealHitrate Real Hitrate 118.28 MHz/cm2
Background Map 250: C13
Plot
RealHitrate Real Hitrate 146.04 MHz/cm2
Retrim Hot Pix 150: C13
Retrim Hot Pix 50: C13
Masked Hot Pixels 50: C13
Masked Hot Pixels 150: C13
Hit Map 50: C13
Plot
RealHitrate Real Hitrate 27.77 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 50: C13
Hit Map 150: C13
Plot
RealHitrate Real Hitrate 84.94 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 150: C13
Col. Read. Unif. 50: C13
Plot
N N 3734935
mu μ 86361
sigma σ 62126.09
Col. Read. Unif. 150: C13
Plot
N N 11512615
mu μ 264156
sigma σ 171481.52
Read. Unif. over Time 50: C13
Plot
N N 4490750
mu μ 4555
sigma_th σ_th 67.49
Time unif. distribution 50: C13
Plot
chi2/ndf chi2/ndf 2.27
sigma σ 72.32
sigma_th σ_th 67.49
expectation Red curve (expected) Poisson
Read. Unif. over Time 150: C13
Plot
N N 13736129
mu μ 13931
sigma_th σ_th 118.03
Time unif. distribution 150: C13
Plot
chi2/ndf chi2/ndf 3.67
sigma σ 130.33
sigma_th σ_th 118.04
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C13
Col. Uniformity per Event: C13 50
Plot
mu μ 21.42
sigma fit error of μ 2.45
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C13 150
Plot
mu μ 21.80
sigma fit error of μ 2.46
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C13 100
Plot
N N 4160
mu μ 160.03
sigma RMS 14.74
threshold thr 1992.91
fit fit Gaussian
fit_peak μ fit 159.62
fit_sigma σ fit 14.18
MeasuredHitrate Measured hitrate: 59.2
Alive Map: C13
DC Efficiency Distribution: C13
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.88
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.18
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C13
