Test Date: 2016-09-05 09:50
Analysis date: 2016-09-05 11:47
Analysis date: 2016-09-05 11:47
M2302 XRayHRQualification
Summary
| Module | Module | M2302 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 25 | |
| BumpBondingDefects | Bump Bonding Defects | 25 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.17 | % |
| Noise | Mean Noise | 162 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.84 | 99.05 | 0.49 | 23.7 | 71.2 | 2 | 0/0 | 0 | 1937 | 167 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 99.18 | 0.91 | 23.8 | 72.7 | 0 | 0/0 | 0 | 1963 | 167 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.00 | 0.58 | 17.9 | 56.3 | 0 | 0/0 | 0 | 1897 | 151 | 0 |
|
Chip 3
|
A
|
3 | 0 | 99.86 | 99.29 | 0.45 | 35.3 | 105.1 | 3 | 0/0 | 0 | 2036 | 164 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.85 | 99.29 | 0.52 | 37.6 | 112.3 | 0 | 0/0 | 0 | 2044 | 163 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.86 | 99.29 | 0.6 | 40.9 | 120.5 | 1 | 0/0 | 0 | 2056 | 157 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.87 | 99.29 | 0.55 | 40.1 | 119.4 | 1 | 0/0 | 0 | 2031 | 162 | 0 |
|
Chip 7
|
A
|
2 | 0 | 99.83 | 99.00 | 0.9 | 41.0 | 122.0 | 2 | 0/0 | 0 | 2067 | 163 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.89 | 99.34 | 0.46 | 36.8 | 111.1 | 0 | 0/0 | 0 | 2042 | 163 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.31 | 0.58 | 42.4 | 126.0 | 0 | 0/0 | 0 | 2059 | 162 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.85 | 98.98 | 0.77 | 40.4 | 119.7 | 1 | 0/0 | 0 | 2061 | 152 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.87 | 99.32 | 0.48 | 40.1 | 119.5 | 1 | 0/0 | 0 | 2082 | 159 | 0 |
|
Chip 12
|
A
|
10 | 0 | 99.88 | 99.32 | 0.46 | 36.2 | 108.1 | 10 | 0/0 | 0 | 2037 | 163 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.15 | 0.64 | 23.1 | 70.7 | 0 | 0/0 | 0 | 1949 | 167 | 0 |
|
Chip 14
|
A
|
2 | 0 | 99.84 | 98.95 | 0.62 | 26.1 | 78.8 | 2 | 0/0 | 0 | 1976 | 169 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.84 | 98.88 | 0.56 | 25.2 | 75.2 | 2 | 0/0 | 0 | 1966 | 164 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-05 | |
| TestTime | Test Time | 09:50 | |
| TestDuration | Duration | 1:31:12 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
