Test Date: 2016-08-22 17:23
Analysis date: 2016-08-29 21:02
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
46.4883125 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
46.4883125 |
|
| medianSlope |
median Slope |
46.4085 |
|
| minSlope |
min Slope |
44.54 |
|
| maxSlope |
max Slope |
48.21 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-199.2648125 |
|
| medianOffset |
median Offset |
-198.091 |
|
| minOffset |
min Offset |
-394.926 |
|
| maxOffset |
max Offset |
-20.655 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
4.2395625 |
|
| medianchi2 |
median chi2 |
1.093 |
|
| minchi2 |
min chi2 |
0.005 |
|
| maxchi2 |
max chi2 |
25.012 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
46.7 e- / Vcal
|
0.1 e- / Vcal
|
-116.3 e-
|
8.4 e-
|
|
1
|
48.2 e- / Vcal
|
0.2 e- / Vcal
|
-144.3 e-
|
19.6 e-
|
|
2
|
46.6 e- / Vcal
|
0.2 e- / Vcal
|
-20.7 e-
|
20.6 e-
|
|
3
|
46.5 e- / Vcal
|
0.2 e- / Vcal
|
-255.1 e-
|
21.7 e-
|
|
4
|
47.9 e- / Vcal
|
0.1 e- / Vcal
|
-224.8 e-
|
7.3 e-
|
|
5
|
46.3 e- / Vcal
|
0.1 e- / Vcal
|
-119.3 e-
|
16.4 e-
|
|
6
|
47.1 e- / Vcal
|
0.1 e- / Vcal
|
-255.6 e-
|
17.1 e-
|
|
7
|
46.3 e- / Vcal
|
0.1 e- / Vcal
|
-177.3 e-
|
17.6 e-
|
|
8
|
45.2 e- / Vcal
|
0.1 e- / Vcal
|
-320.2 e-
|
6.3 e-
|
|
9
|
44.5 e- / Vcal
|
0.1 e- / Vcal
|
-255.0 e-
|
8.5 e-
|
|
10
|
45.5 e- / Vcal
|
0.1 e- / Vcal
|
-187.1 e-
|
6.3 e-
|
|
11
|
47.9 e- / Vcal
|
0.1 e- / Vcal
|
-73.0 e-
|
16.8 e-
|
|
12
|
45.4 e- / Vcal
|
0.1 e- / Vcal
|
-209.0 e-
|
18.2 e-
|
|
13
|
47.8 e- / Vcal
|
0.2 e- / Vcal
|
-394.9 e-
|
21.9 e-
|
|
14
|
45.8 e- / Vcal
|
0.1 e- / Vcal
|
-186.6 e-
|
6.5 e-
|
|
15
|
46.1 e- / Vcal
|
0.1 e- / Vcal
|
-248.9 e-
|
18.6 e-
|
|
Average
|
46.5 e- / Vcal
|
|
-199.3 e-
|
|
|
Median
|
91.5 e- / Vcal
|
|
-497.5 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
