Test Date: 2016-08-10 11:12
Analysis date: 2016-08-10 16:00
Analysis date: 2016-08-10 16:00
M2290 XRayHRQualification
Summary
| Module | Module | M2290 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.17 | % |
| Noise | Mean Noise | 172 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.86 | 99.12 | 0.63 | 66.7 | 1 | 21.8 | 0/0 | 0 | 1914 | 163 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 98.94 | 0.79 | 71.7 | 0 | 23.4 | 0/0 | 0 | 1923 | 170 | 0 |
|
Chip 2
|
A
|
2 | 0 | 99.86 | 99.15 | 0.34 | 64.3 | 2 | 20.7 | 0/0 | 0 | 1890 | 166 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.85 | 99.23 | 0.66 | 111.9 | 0 | 37.1 | 0/0 | 0 | 2021 | 175 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.84 | 98.98 | 0.59 | 115.3 | 0 | 38.1 | 0/0 | 0 | 2017 | 173 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.28 | 0.6 | 154.2 | 0 | 52.5 | 0/0 | 0 | 2110 | 175 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.29 | 0.51 | 142.4 | 0 | 48.1 | 0/0 | 0 | 2081 | 169 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.29 | 0.53 | 135.8 | 0 | 45.3 | 0/0 | 0 | 2056 | 166 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.28 | 0.85 | 159.4 | 0 | 53.9 | 0/0 | 0 | 2112 | 177 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.28 | 0.86 | 148.1 | 0 | 49.8 | 0/0 | 0 | 2086 | 169 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.31 | 0.71 | 167.8 | 0 | 57.0 | 0/0 | 0 | 2134 | 177 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.85 | 99.14 | 0.73 | 124.0 | 0 | 41.4 | 0/0 | 0 | 2027 | 169 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.24 | 0.89 | 116.8 | 0 | 38.9 | 0/0 | 0 | 2009 | 169 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 98.95 | 0.64 | 72.3 | 0 | 23.5 | 0/0 | 0 | 1929 | 168 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 98.95 | 0.64 | 80.4 | 0 | 26.5 | 0/0 | 0 | 1953 | 175 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.87 | 99.24 | 0.76 | 77.6 | 0 | 25.8 | 0/0 | 0 | 1895 | 185 | 2 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-08-10 | |
| TestTime | Test Time | 11:12 | |
| TestDuration | Duration | 1:32:15 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
