Test Date: 2016-08-10 11:12
Analysis date: 2016-08-10 13:30
Analysis date: 2016-08-10 13:30
M2288 XRayHRQualification
Summary
| Module | Module | M2288 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 4 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 3 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.21 | % |
| Noise | Mean Noise | 166 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 98.94 | 0.86 | 32.5 | 96.1 | 0 | 0/0 | 0 | 2030 | 173 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.28 | 0.5 | 30.5 | 92.4 | 0 | 0/0 | 0 | 2000 | 166 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.85 | 99.15 | 0.53 | 28.7 | 87.5 | 0 | 0/0 | 0 | 1932 | 161 | 1 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.31 | 0.69 | 49.3 | 144.6 | 0 | 0/0 | 0 | 2121 | 166 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.29 | 0.74 | 51.4 | 151.4 | 0 | 0/0 | 0 | 2125 | 171 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.26 | 0.62 | 68.2 | 195.9 | 0 | 0/0 | 0 | 2228 | 165 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.86 | 99.25 | 0.62 | 65.2 | 190.2 | 0 | 0/0 | 0 | 2209 | 166 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.28 | 0.47 | 62.0 | 181.9 | 0 | 0/0 | 0 | 2165 | 161 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.29 | 0.48 | 60.6 | 177.6 | 0 | 0/0 | 0 | 2194 | 166 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.28 | 0.48 | 62.6 | 182.1 | 0 | 0/0 | 0 | 2188 | 162 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.87 | 99.32 | 0.64 | 64.3 | 184.5 | 0 | 0/0 | 0 | 2194 | 163 | 1 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.25 | 0.49 | 51.7 | 152.7 | 0 | 0/0 | 0 | 2125 | 172 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.85 | 99.22 | 0.71 | 49.4 | 145.3 | 0 | 0/0 | 0 | 2136 | 169 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.85 | 99.23 | 0.46 | 28.6 | 87.2 | 0 | 0/0 | 0 | 1956 | 161 | 1 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 98.93 | 0.58 | 31.1 | 93.2 | 0 | 0/0 | 0 | 2025 | 170 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 99.05 | 0.85 | 32.9 | 97.3 | 0 | 0/0 | 0 | 2028 | 169 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-08-10 | |
| TestTime | Test Time | 11:12 | |
| TestDuration | Duration | 1:32:15 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
