Test Date: 2016-08-10 08:59
Analysis date: 2016-08-10 11:28
Analysis date: 2016-08-10 11:28
M2286 XRayHRQualification
Summary
| Module | Module | M2286 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 76 | |
| BumpBondingDefects | Bump Bonding Defects | 73 | |
| NoisyPixels | Noisy Pixels | 3 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.19 | % |
| Noise | Mean Noise | 166 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
6 | 0 | 99.83 | 98.94 | 0.48 | 23.1 | 69.7 | 4 | 0/0 | 0 | 1888 | 170 | 2 |
|
Chip 1
|
A
|
13 | 0 | 99.81 | 98.97 | 0.54 | 23.5 | 71.3 | 13 | 0/0 | 0 | 1968 | 159 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.32 | 0.5 | 22.1 | 67.6 | 0 | 0/0 | 0 | 1948 | 183 | 0 |
|
Chip 3
|
A
|
3 | 0 | 99.86 | 99.07 | 0.66 | 36.9 | 110.3 | 3 | 0/0 | 0 | 2059 | 173 | 0 |
|
Chip 4
|
A
|
5 | 0 | 99.86 | 99.23 | 0.59 | 36.4 | 108.8 | 5 | 0/0 | 0 | 2041 | 165 | 0 |
|
Chip 5
|
A
|
3 | 0 | 99.88 | 99.29 | 0.59 | 47.9 | 139.7 | 3 | 0/0 | 0 | 2116 | 162 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.87 | 99.27 | 1.01 | 43.3 | 127.5 | 1 | 0/0 | 0 | 2102 | 163 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.15 | 0.88 | 45.4 | 135.1 | 0 | 0/0 | 0 | 2128 | 170 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.86 | 99.30 | 0.47 | 50.2 | 148.9 | 1 | 0/0 | 0 | 2150 | 167 | 0 |
|
Chip 9
|
A
|
4 | 0 | 99.86 | 99.24 | 0.63 | 48.4 | 141.4 | 4 | 0/0 | 0 | 2122 | 159 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.87 | 99.28 | 0.46 | 47.2 | 137.5 | 1 | 0/0 | 0 | 2133 | 161 | 0 |
|
Chip 11
|
A
|
12 | 0 | 99.87 | 99.24 | 0.55 | 38.3 | 114.9 | 12 | 0/0 | 0 | 2054 | 162 | 0 |
|
Chip 12
|
A
|
21 | 0 | 99.85 | 99.03 | 0.53 | 36.2 | 107.7 | 20 | 0/0 | 0 | 2011 | 167 | 1 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.23 | 0.42 | 23.0 | 70.2 | 0 | 0/0 | 0 | 1972 | 157 | 0 |
|
Chip 14
|
A
|
5 | 0 | 99.85 | 99.21 | 0.59 | 26.6 | 80.5 | 5 | 0/0 | 0 | 1989 | 174 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.85 | 99.26 | 0.59 | 24.5 | 73.7 | 1 | 0/0 | 0 | 1971 | 167 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-08-10 | |
| TestTime | Test Time | 08:59 | |
| TestDuration | Duration | 1:33:13 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
