Test Date: 2016-08-10 16:30
Analysis date: 2016-08-10 18:14
Analysis date: 2016-08-10 18:14
M2284 XRayHRQualification
Summary
| Module | Module | M2284 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 20 | |
| BumpBondingDefects | Bump Bonding Defects | 10 | |
| NoisyPixels | Noisy Pixels | 9 | |
| HotPixelDefects | Hot Pixels | 4 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.14 | % |
| Noise | Mean Noise | 169 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 98.96 | 0.54 | 25.2 | 76.5 | 0 | 0/0 | 0 | 1962 | 176 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 98.95 | 0.76 | 25.6 | 78.0 | 0 | 0/0 | 0 | 1965 | 171 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.83 | 99.06 | 0.46 | 20.8 | 64.7 | 1 | 0/0 | 0 | 1926 | 163 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.85 | 99.24 | 0.57 | 38.6 | 115.9 | 1 | 0/0 | 0 | 2060 | 171 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.25 | 0.46 | 38.2 | 114.9 | 0 | 0/0 | 0 | 2028 | 167 | 0 |
|
Chip 5
|
A
|
3 | 0 | 99.86 | 99.29 | 0.53 | 50.4 | 148.3 | 3 | 0/0 | 0 | 2118 | 170 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.24 | 0.6 | 43.8 | 129.6 | 0 | 0/0 | 0 | 2044 | 163 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.26 | 0.74 | 48.8 | 145.1 | 0 | 0/0 | 0 | 2101 | 169 | 0 |
|
Chip 8
|
A
|
8 | 0 | 99.86 | 99.31 | 0.8 | 44.5 | 131.7 | 0 | 0/0 | 0 | 1786 | 172 | 8 |
|
Chip 9
|
A
|
1 | 0 | 99.82 | 99.00 | 0.68 | 45.6 | 135.2 | 0 | 0/0 | 0 | 2081 | 168 | 1 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.18 | 0.94 | 45.4 | 133.3 | 0 | 0/0 | 0 | 2085 | 160 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.21 | 1.08 | 36.6 | 110.3 | 0 | 0/0 | 0 | 2052 | 171 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.84 | 98.99 | 0.79 | 36.0 | 108.9 | 0 | 0/0 | 0 | 2035 | 178 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.05 | 0.57 | 20.5 | 63.7 | 0 | 0/0 | 0 | 1924 | 168 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.84 | 99.10 | 0.9 | 21.7 | 66.9 | 1 | 0/0 | 0 | 1953 | 160 | 0 |
|
Chip 15
|
A
|
4 | 0 | 99.85 | 99.19 | 0.52 | 22.9 | 69.9 | 4 | 0/0 | 0 | 1948 | 176 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-08-10 | |
| TestTime | Test Time | 16:30 | |
| TestDuration | Duration | 1:26:52 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
