Test Date: 2016-08-03 11:22
Analysis date: 2016-08-04 09:49
Analysis date: 2016-08-04 09:49
M2279 XRayHRQualification
Summary
| Module | Module | M2279 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 9 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.23 | % |
| Noise | Mean Noise | 167 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.85 | 99.20 | 0.61 | 29.7 | 88.8 | 0 | 0/0 | 0 | 1988 | 164 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.88 | 99.26 | 0.55 | 33.8 | 100.8 | 0 | 0/0 | 0 | 2022 | 171 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.85 | 99.24 | 0.81 | 28.4 | 86.6 | 0 | 0/0 | 0 | 1954 | 164 | 1 |
|
Chip 3
|
A
|
0 | 0 | 99.84 | 99.23 | 0.97 | 54.6 | 159.9 | 0 | 0/0 | 0 | 2172 | 161 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.28 | 0.64 | 57.1 | 167.9 | 0 | 0/0 | 0 | 2175 | 170 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.32 | 0.78 | 71.5 | 206.0 | 0 | 0/0 | 0 | 2250 | 173 | 0 |
|
Chip 6
|
A
|
4 | 0 | 99.88 | 99.30 | 0.63 | 71.2 | 208.1 | 0 | 0/0 | 0 | 2270 | 183 | 0 |
|
Chip 7
|
A
|
2 | 0 | 99.90 | 99.29 | 0.5 | 72.7 | 212.1 | 2 | 0/0 | 0 | 2266 | 173 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.84 | 99.29 | 0.61 | 66.8 | 193.6 | 0 | 0/0 | 0 | 2215 | 161 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.84 | 99.27 | 1.37 | 69.7 | 202.3 | 0 | 0/0 | 0 | 2241 | 167 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.89 | 99.32 | 0.65 | 67.6 | 192.7 | 0 | 0/0 | 0 | 2232 | 154 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.25 | 0.58 | 54.4 | 159.2 | 0 | 0/0 | 0 | 2148 | 164 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.32 | 0.81 | 49.3 | 144.6 | 0 | 0/0 | 0 | 2126 | 159 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 98.94 | 0.89 | 28.4 | 86.3 | 0 | 0/0 | 0 | 1983 | 161 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.86 | 99.24 | 0.73 | 33.1 | 99.1 | 0 | 0/0 | 0 | 2030 | 173 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.81 | 98.94 | 0.8 | 31.6 | 94.1 | 0 | 0/0 | 0 | 1967 | 173 | 1 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-08-03 | |
| TestTime | Test Time | 11:22 | |
| TestDuration | Duration | 1:25:54 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
