Test Date: 2016-07-25 09:53
Analysis date: 2016-07-25 11:43
Analysis date: 2016-07-25 11:43
M2274 XRayHRQualification
Summary
| Module | Module | M2274 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 57 | |
| BumpBondingDefects | Bump Bonding Defects | 51 | |
| NoisyPixels | Noisy Pixels | 6 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.34 | % |
| Noise | Mean Noise | 169 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.88 | 99.35 | 0.48 | 29.2 | 86.7 | 3 | 0/0 | 0 | 1977 | 164 | 0 |
|
Chip 1
|
A
|
7 | 0 | 99.88 | 99.35 | 0.51 | 33.6 | 99.0 | 7 | 0/0 | 0 | 2014 | 170 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 99.14 | 0.54 | 31.6 | 94.6 | 0 | 0/0 | 0 | 1977 | 181 | 0 |
|
Chip 3
|
A
|
9 | 0 | 99.89 | 99.41 | 0.42 | 53.1 | 152.3 | 9 | 0/0 | 0 | 2137 | 173 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.88 | 99.37 | 0.63 | 54.8 | 157.6 | 0 | 0/0 | 0 | 2103 | 164 | 1 |
|
Chip 5
|
A
|
2 | 0 | 99.89 | 99.41 | 0.66 | 68.4 | 193.8 | 2 | 0/0 | 0 | 2215 | 170 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.90 | 99.42 | 0.57 | 69.2 | 198.8 | 0 | 0/0 | 0 | 2232 | 170 | 0 |
|
Chip 7
|
A
|
4 | 0 | 99.89 | 99.42 | 0.35 | 67.8 | 193.0 | 0 | 0/0 | 0 | 2080 | 169 | 4 |
|
Chip 8
|
A
|
5 | 0 | 99.88 | 99.41 | 0.47 | 63.0 | 178.2 | 5 | 0/0 | 0 | 2196 | 165 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.35 | 0.71 | 61.7 | 175.6 | 0 | 0/0 | 0 | 2164 | 164 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.89 | 99.40 | 0.48 | 68.1 | 190.8 | 0 | 0/0 | 0 | 2217 | 172 | 0 |
|
Chip 11
|
A
|
5 | 0 | 99.88 | 99.35 | 0.63 | 54.3 | 155.7 | 5 | 0/0 | 0 | 2142 | 166 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.87 | 99.33 | 0.6 | 53.1 | 151.5 | 0 | 0/0 | 0 | 2128 | 172 | 1 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.30 | 0.48 | 30.5 | 91.1 | 0 | 0/0 | 0 | 1995 | 171 | 0 |
|
Chip 14
|
A
|
5 | 0 | 99.86 | 99.09 | 0.51 | 31.5 | 93.5 | 5 | 0/0 | 0 | 1963 | 163 | 0 |
|
Chip 15
|
A
|
15 | 0 | 99.88 | 99.35 | 0.46 | 29.4 | 86.7 | 15 | 0/0 | 0 | 1971 | 171 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-07-25 | |
| TestTime | Test Time | 09:53 | |
| TestDuration | Duration | 1:32:29 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
