Module | Module | M2270 | |
Grade | Grade | A | |
ElectricalGrade | Electrical Grade | A | |
IVGrade | IV Grade | A | |
ManualGrade | Manual Grade | None | |
PixelDefects | Pixel Defects - A/B/C | 18 - 16/0/0 | |
DeadPixels | Dead Pixels | 1 | |
AddressProblems | Address Problems | 0 | |
ThresholdDefects | Threshold Defects | 17 | |
MaskDefects | Mask Defects | 0 | |
DeadBumps | Dead Bumps | 0 | |
NoisyPixels | Noise Defects | 0 | |
TrimProblems | Trim Problems | 0 | |
PHGainDefects | PH Gain Defects | 0 | |
PHPar1Defects | PH Parameter1 Defects | 0 |
TestCenter | Test Center | ETH | |
TestDate | Test Date | 2016-06-30 | |
TestTime | Test Time | 12:11 | |
TestDuration | Duration | 1:24:23 | |
TempC | Temparature | 17 | °C |
TBM1 | TBM1 | ok, 0x34 0x64 | |
TBM2 | TBM2 | ok, 0x00 0x64 | |
PxarVersion | pXar | v2.7.5+16 g4df2ad8 | |
DTB_FW | DTB FW | 4.6 | |
ModuleIa | Module Ia | 377 | mA |
Noise | Noise | 159.94 | e |
NoiseROCs | Noise grades | 16/0/0 | |
VcalThrWidth | Vcal Thr. Width | 47.19 | e |
VcalThrWidthROCs | Vcal Thr. W. grades | 16/0/0 | |
RelGainWidth | Rel. Gain Width | 0.04 | % |
RelGainWidthROCs | Rel. Gain W. grades | 16/0/0 | |
PedestalSpread | Pedestal Spread | 1231.28 | e |
PedestalSpreadROCs | Ped. Spread grades | 16/0/0 | |
Parameter1 | Parameter1 | 0.74 | |
Parameter1ROCs | Par1 grades | 16/0/0 | |
CurrentAtVoltage150V | I(150 V) | 0.37 | μA |
CurrentVariation | I(150 V) / I(100 V) | 1.05 |
Duration | Duration | 1:24:23 | |
MinCurrent | min. Current | 0.379 | A |
MaxCurrent | max. Current | 0.487 | A |
Duration | Duration | 1:24:23 | |
MinCurrent | min. Current | 0.074 | A |
MaxCurrent | max. Current | 0.38 | A |
ModuleIa | Module Ia | 377 | mA |
IanaLossProblems | Iana problems | No | |
Mean | mean | 18.30 | |
Min | min | 17.70 | |
Max | max | 19.30 | |
NROCsNotProgrammable | ROCs not programmable | 0 |
Temperature | Temp. while test | 17.00 +/- 0.07 | °C |
Duration | Duration of test | 1:24:25 |
ROC | Grade | Total | Dead | Mask | Bumps | Trim(Bits) | Address | Noise | Thresh | Gain | Ped | Par1 | Mean noise | Thr [e-] | Thr width | Rel gain width | Ped spread |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Chip 0 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
149.47
|
1749 |
44
|
0.043
|
1406
|
Chip 1 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
154.88
|
1748 |
44
|
0.044
|
1195
|
Chip 2 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
155.02
|
1748 |
44
|
0.034
|
1032
|
Chip 3 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
167.72
|
1748 |
44
|
0.035
|
1282
|
Chip 4 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
172.69
|
1745 |
53
|
0.050
|
1472
|
Chip 5 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
151.41
|
1748 |
44
|
0.036
|
1205
|
Chip 6 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
146.96
|
1750 |
44
|
0.043
|
1270
|
Chip 7 |
A
|
2
|
1
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
155.18
|
1745 |
45
|
0.031
|
1140
|
Chip 8 |
A
|
5
|
0
|
0
|
0
|
0
|
0
|
0
|
5
|
0
|
0
|
0
|
155.90
|
1752 |
53
|
0.044
|
1314
|
Chip 9 |
A
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
2
|
0
|
0
|
0
|
158.48
|
1748 |
48
|
0.029
|
1208
|
Chip 10 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
167.56
|
1750 |
45
|
0.035
|
1170
|
Chip 11 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
162.79
|
1750 |
46
|
0.037
|
1259
|
Chip 12 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
164.20
|
1748 |
46
|
0.034
|
1246
|
Chip 13 |
A
|
5
|
0
|
0
|
0
|
0
|
0
|
0
|
5
|
0
|
0
|
0
|
169.67
|
1750 |
58
|
0.035
|
1182
|
Chip 14 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
159.30
|
1748 |
49
|
0.050
|
1140
|
Chip 15 |
A
|
4
|
0
|
0
|
0
|
0
|
0
|
0
|
4
|
0
|
0
|
0
|
167.84
|
1747 |
48
|
0.050
|
1180
|
ModifiedGrading | Modified Grading | True | |
GradingParameters_leakageCurrentRatioB | leakageCurrentRatioB | 20 => -111 |
nTBMs | n | 1 | |
TBMType | Type | tbm09c | |
Core0a_basea | Core 0a base a | 0x64 | |
Core0a_basee | Core 0a base e | 0x34 | |
Core0b_basea | Core 0b base a | 0x64 | |
Core0b_basee | Core 0b base e | 0x00 | |
RocDelay_Ch0 | Roc Delay Ch0 | 4 | |
RocDelay_Ch1 | Roc Delay Ch1 | 4 | |
RocDelay_Ch2 | Roc Delay Ch2 | 4 | |
RocDelay_Ch3 | Roc Delay Ch3 | 4 | |
Phase400 | Phase 400 | 5 | |
Phase160 | Phase 160 | 1 |
nCriticals | # Criticals | 0 | |
nErrors | # Errors | 2 | |
nWarnings | # Warnings | 0 | |
channel_0_count | Channel 0 | 2 | |
channel_1_count | Channel 1 | 0 | |
channel_2_count | Channel 2 | 0 | |
channel_3_count | Channel 3 | 0 | |
message_eventid_count | Event ID mismatch | 1 | |
message_tokenchain_count | Token Chain Length | 1 |
