Test Date: 2016-06-30 09:26
Analysis date: 2016-06-30 13:32
Analysis date: 2016-06-30 13:32
M2266 XRayHRQualification
Summary
| Module | Module | M2266 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 144 | |
| BumpBondingDefects | Bump Bonding Defects | 144 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.28 | % |
| Noise | Mean Noise | 168 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
21 | 0 | 99.86 | 99.05 | 0.6 | 75.0 | 21 | 25.1 | 0/0 | 0 | 1961 | 164 | 0 |
|
Chip 1
|
A
|
13 | 0 | 99.87 | 99.27 | 0.57 | 78.0 | 13 | 25.9 | 0/0 | 0 | 1972 | 169 | 0 |
|
Chip 2
|
A
|
26 | 0 | 99.88 | 99.33 | 0.48 | 70.6 | 26 | 23.1 | 0/0 | 0 | 1964 | 173 | 0 |
|
Chip 3
|
A
|
7 | 0 | 99.88 | 99.40 | 0.47 | 133.9 | 7 | 45.8 | 0/0 | 0 | 2141 | 174 | 0 |
|
Chip 4
|
A
|
15 | 0 | 99.88 | 99.35 | 0.52 | 121.4 | 15 | 41.2 | 0/0 | 0 | 2077 | 167 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.89 | 99.33 | 1.34 | 135.5 | 1 | 46.5 | 0/0 | 0 | 2111 | 163 | 0 |
|
Chip 6
|
A
|
6 | 0 | 99.88 | 99.36 | 0.58 | 150.2 | 6 | 51.8 | 0/0 | 0 | 2151 | 172 | 0 |
|
Chip 7
|
A
|
6 | 0 | 99.87 | 99.38 | 0.6 | 134.1 | 6 | 45.8 | 0/0 | 0 | 2112 | 164 | 0 |
|
Chip 8
|
A
|
12 | 0 | 99.88 | 99.32 | 0.43 | 125.2 | 12 | 42.5 | 0/0 | 0 | 2060 | 167 | 0 |
|
Chip 9
|
A
|
2 | 0 | 99.89 | 99.39 | 0.52 | 124.5 | 2 | 42.4 | 0/0 | 0 | 2060 | 165 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.88 | 99.38 | 0.55 | 126.5 | 1 | 43.4 | 0/0 | 0 | 2092 | 159 | 0 |
|
Chip 11
|
A
|
4 | 0 | 99.88 | 99.36 | 0.57 | 112.8 | 4 | 38.0 | 0/0 | 0 | 2066 | 169 | 0 |
|
Chip 12
|
A
|
5 | 0 | 99.87 | 99.07 | 0.44 | 101.6 | 5 | 33.9 | 0/0 | 0 | 2021 | 165 | 0 |
|
Chip 13
|
A
|
8 | 0 | 99.84 | 99.08 | 0.44 | 61.7 | 8 | 20.0 | 0/0 | 0 | 1947 | 166 | 0 |
|
Chip 14
|
A
|
8 | 0 | 99.87 | 99.36 | 0.43 | 74.8 | 8 | 24.7 | 0/0 | 0 | 1968 | 173 | 0 |
|
Chip 15
|
A
|
9 | 0 | 99.85 | 98.99 | 0.43 | 71.9 | 9 | 23.9 | 0/0 | 0 | 1951 | 172 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-06-30 | |
| TestTime | Test Time | 09:26 | |
| TestDuration | Duration | 1:24:44 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.1-7-g5388ca4 on branch psi46master
