Test Date: 2016-06-29 10:04
Analysis date: 2016-06-29 11:49
Analysis date: 2016-06-29 11:49
M2265 XRayHRQualification
Summary
| Module | Module | M2265 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 19 | |
| BumpBondingDefects | Bump Bonding Defects | 19 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.27 | % |
| Noise | Mean Noise | 169 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.89 | 99.33 | 0.27 | 22.1 | 66.5 | 2 | 0/0 | 0 | 1961 | 164 | 0 |
|
Chip 1
|
A
|
3 | 0 | 99.85 | 99.05 | 0.72 | 23.2 | 69.7 | 3 | 0/0 | 0 | 1950 | 167 | 0 |
|
Chip 2
|
A
|
3 | 0 | 99.85 | 99.19 | 0.5 | 20.0 | 61.0 | 3 | 0/0 | 0 | 1908 | 168 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.89 | 99.34 | 0.53 | 38.1 | 111.7 | 0 | 0/0 | 0 | 2069 | 172 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.88 | 99.30 | 0.62 | 39.7 | 116.5 | 2 | 0/0 | 0 | 2057 | 181 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.33 | 0.44 | 44.3 | 128.3 | 0 | 0/0 | 0 | 2088 | 165 | 0 |
|
Chip 6
|
A
|
5 | 0 | 99.87 | 99.30 | 0.54 | 47.0 | 137.2 | 5 | 0/0 | 0 | 2112 | 173 | 0 |
|
Chip 7
|
A
|
2 | 0 | 99.88 | 99.35 | 0.44 | 38.6 | 114.5 | 2 | 0/0 | 0 | 2045 | 165 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.33 | 0.53 | 44.6 | 130.5 | 0 | 0/0 | 0 | 2086 | 169 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.35 | 0.75 | 52.2 | 151.0 | 0 | 0/0 | 0 | 2123 | 174 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.30 | 0.68 | 48.0 | 138.6 | 0 | 0/0 | 0 | 2115 | 157 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.85 | 99.19 | 0.64 | 42.6 | 124.4 | 0 | 0/0 | 0 | 2095 | 169 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.89 | 99.33 | 0.6 | 40.3 | 118.1 | 0 | 0/0 | 0 | 2065 | 170 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.88 | 99.34 | 0.37 | 23.5 | 71.3 | 0 | 0/0 | 0 | 1941 | 170 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.87 | 99.06 | 0.5 | 24.2 | 73.5 | 0 | 0/0 | 0 | 1933 | 167 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.88 | 99.29 | 0.38 | 25.8 | 76.8 | 2 | 0/0 | 0 | 1966 | 168 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-06-29 | |
| TestTime | Test Time | 10:04 | |
| TestDuration | Duration | 1:22:20 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.1-7-g5388ca4 on branch psi46master
