Test Date: 2016-07-04 10:02
Analysis date: 2016-07-04 11:38
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
46.1628125 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
46.1628125 |
|
| medianSlope |
median Slope |
46.031 |
|
| minSlope |
min Slope |
42.769 |
|
| maxSlope |
max Slope |
48.894 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-60.633125 |
|
| medianOffset |
median Offset |
-52.153 |
|
| minOffset |
min Offset |
-258.394 |
|
| maxOffset |
max Offset |
100.274 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
2.23275 |
|
| medianchi2 |
median chi2 |
1.4655 |
|
| minchi2 |
min chi2 |
0.002 |
|
| maxchi2 |
max chi2 |
6.426 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
45.2 e- / Vcal
|
0.1 e- / Vcal
|
-196.3 e-
|
18.1 e-
|
|
1
|
46.9 e- / Vcal
|
0.1 e- / Vcal
|
-66.7 e-
|
18.2 e-
|
|
2
|
44.5 e- / Vcal
|
0.2 e- / Vcal
|
55.2 e-
|
19.3 e-
|
|
3
|
48.4 e- / Vcal
|
0.1 e- / Vcal
|
21.6 e-
|
16.2 e-
|
|
4
|
47.0 e- / Vcal
|
0.1 e- / Vcal
|
57.4 e-
|
6.8 e-
|
|
5
|
46.0 e- / Vcal
|
0.1 e- / Vcal
|
-258.4 e-
|
16.7 e-
|
|
6
|
48.3 e- / Vcal
|
0.1 e- / Vcal
|
-199.1 e-
|
17.8 e-
|
|
7
|
45.3 e- / Vcal
|
0.1 e- / Vcal
|
-73.2 e-
|
17.8 e-
|
|
8
|
42.8 e- / Vcal
|
0.1 e- / Vcal
|
51.6 e-
|
17.2 e-
|
|
9
|
45.2 e- / Vcal
|
0.1 e- / Vcal
|
72.9 e-
|
15.9 e-
|
|
10
|
45.8 e- / Vcal
|
0.1 e- / Vcal
|
-181.6 e-
|
16.4 e-
|
|
11
|
46.1 e- / Vcal
|
0.1 e- / Vcal
|
-8.0 e-
|
11.4 e-
|
|
12
|
47.3 e- / Vcal
|
0.1 e- / Vcal
|
-37.6 e-
|
9.7 e-
|
|
13
|
44.4 e- / Vcal
|
0.2 e- / Vcal
|
100.3 e-
|
20.7 e-
|
|
14
|
48.9 e- / Vcal
|
0.1 e- / Vcal
|
-202.1 e-
|
17.6 e-
|
|
15
|
46.7 e- / Vcal
|
0.2 e- / Vcal
|
-106.1 e-
|
19.7 e-
|
|
Average
|
46.2 e- / Vcal
|
|
-60.6 e-
|
|
|
Median
|
88.1 e- / Vcal
|
|
-21.6 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
