Test Date: 2016-07-04 10:02
Analysis date: 2016-07-04 11:38
Analysis date: 2016-07-04 11:38
M2263 XRayHRQualification
Summary
| Module | Module | M2263 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.30 | % |
| Noise | Mean Noise | 167 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.88 | 99.34 | 0.53 | 33.0 | 97.4 | 0 | 0/0 | 0 | 2008 | 181 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.30 | 0.63 | 32.9 | 98.0 | 0 | 0/0 | 0 | 2028 | 168 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 99.30 | 1.13 | 30.0 | 90.3 | 0 | 0/0 | 0 | 2000 | 176 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.10 | 0.98 | 48.1 | 140.4 | 0 | 0/0 | 0 | 2137 | 159 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.37 | 0.48 | 51.3 | 149.1 | 0 | 0/0 | 0 | 2160 | 161 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.85 | 99.42 | 0.49 | 69.7 | 197.9 | 0 | 0/0 | 0 | 2253 | 161 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.26 | 1.75 | 61.7 | 177.8 | 0 | 0/0 | 0 | 2186 | 153 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.20 | 0.88 | 72.6 | 207.9 | 0 | 0/0 | 0 | 2256 | 162 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.90 | 99.40 | 0.36 | 69.8 | 199.6 | 0 | 0/0 | 0 | 2242 | 172 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.39 | 0.47 | 65.9 | 187.7 | 0 | 0/0 | 0 | 2251 | 171 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.39 | 0.49 | 69.4 | 195.2 | 0 | 0/0 | 0 | 2252 | 162 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.89 | 99.36 | 0.53 | 56.5 | 163.8 | 0 | 0/0 | 0 | 2173 | 165 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.88 | 99.17 | 0.52 | 48.6 | 141.0 | 0 | 0/0 | 0 | 2117 | 166 | 1 |
|
Chip 13
|
A
|
1 | 0 | 99.88 | 99.36 | 0.43 | 29.6 | 88.9 | 1 | 0/0 | 0 | 2026 | 177 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.89 | 99.34 | 0.34 | 29.6 | 88.9 | 0 | 0/0 | 0 | 2015 | 167 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 99.06 | 0.55 | 30.6 | 90.4 | 0 | 0/0 | 0 | 1991 | 177 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-07-04 | |
| TestTime | Test Time | 10:02 | |
| TestDuration | Duration | 1:24:30 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.1-7-g5388ca4 on branch psi46master
