Test Date: 2016-06-16 14:58
Analysis date: 2016-06-16 16:38
Analysis date: 2016-06-16 16:38
M2259 XRayHRQualification
Summary
| Module | Module | M2259 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 1 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.33 | % |
| Noise | Mean Noise | 170 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.87 | 99.27 | 0.47 | 29.7 | 88.5 | 0 | 0/0 | 0 | 1997 | 178 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.37 | 0.46 | 28.6 | 86.7 | 0 | 0/0 | 0 | 2001 | 172 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.26 | 0.32 | 28.5 | 86.7 | 0 | 0/0 | 0 | 1990 | 184 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.39 | 0.49 | 48.3 | 140.8 | 0 | 0/0 | 0 | 2125 | 176 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.87 | 99.35 | 0.76 | 52.7 | 153.5 | 0 | 0/0 | 0 | 2125 | 173 | 1 |
|
Chip 5
|
A
|
0 | 0 | 99.90 | 99.41 | 0.65 | 60.4 | 172.7 | 0 | 0/0 | 0 | 2177 | 169 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.89 | 99.31 | 0.58 | 56.6 | 162.7 | 0 | 0/0 | 0 | 2129 | 163 | 1 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.37 | 0.76 | 59.5 | 171.6 | 0 | 0/0 | 0 | 2190 | 161 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.33 | 0.6 | 61.1 | 175.4 | 0 | 0/0 | 0 | 2173 | 166 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.33 | 0.9 | 65.4 | 189.2 | 0 | 0/0 | 0 | 2231 | 173 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.22 | 0.74 | 62.0 | 178.1 | 0 | 0/0 | 0 | 2206 | 168 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.89 | 99.35 | 0.59 | 45.8 | 135.3 | 0 | 0/0 | 0 | 2126 | 162 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.34 | 0.58 | 49.2 | 144.6 | 0 | 0/0 | 0 | 2139 | 173 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.34 | 0.42 | 26.4 | 81.1 | 0 | 0/0 | 0 | 1993 | 167 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.88 | 99.32 | 0.52 | 28.2 | 86.0 | 0 | 0/0 | 0 | 1978 | 167 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.87 | 99.30 | 0.44 | 29.3 | 87.9 | 0 | 0/0 | 0 | 1990 | 174 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-06-16 | |
| TestTime | Test Time | 14:58 | |
| TestDuration | Duration | 1:26:58 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
