Test Date: 2016-06-15 15:42
Analysis date: 2016-06-15 17:27
Analysis date: 2016-06-15 17:27
M2256 XRayHRQualification
Summary
| Module | Module | M2256 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 16 | |
| BumpBondingDefects | Bump Bonding Defects | 12 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.27 | % |
| Noise | Mean Noise | 170 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.85 | 98.96 | 0.35 | 21.1 | 64.6 | 0 | 0/0 | 0 | 1936 | 171 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.31 | 0.36 | 22.7 | 69.8 | 0 | 0/0 | 0 | 1957 | 170 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.04 | 0.77 | 20.9 | 64.3 | 0 | 0/0 | 0 | 1919 | 174 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.33 | 0.43 | 32.7 | 97.5 | 0 | 0/0 | 0 | 2031 | 168 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.86 | 99.32 | 0.93 | 36.4 | 107.8 | 0 | 0/0 | 0 | 2059 | 170 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.88 | 99.36 | 0.54 | 47.3 | 137.0 | 0 | 0/0 | 0 | 2131 | 178 | 1 |
|
Chip 6
|
A
|
2 | 0 | 99.87 | 99.34 | 0.38 | 39.5 | 116.5 | 1 | 0/0 | 0 | 2031 | 167 | 1 |
|
Chip 7
|
A
|
0 | 0 | 99.89 | 99.35 | 0.52 | 39.6 | 117.4 | 0 | 0/0 | 0 | 2061 | 166 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.88 | 99.10 | 0.58 | 45.4 | 133.8 | 1 | 0/0 | 0 | 2104 | 170 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.87 | 99.32 | 0.57 | 41.4 | 123.3 | 1 | 0/0 | 0 | 2068 | 161 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.35 | 0.66 | 50.3 | 145.5 | 0 | 0/0 | 0 | 2151 | 171 | 0 |
|
Chip 11
|
A
|
2 | 0 | 99.87 | 99.35 | 0.78 | 45.2 | 133.1 | 1 | 0/0 | 0 | 2125 | 177 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.34 | 0.54 | 35.5 | 106.3 | 0 | 0/0 | 0 | 2041 | 171 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.39 | 0.33 | 22.9 | 70.3 | 0 | 0/0 | 0 | 1959 | 170 | 0 |
|
Chip 14
|
A
|
2 | 0 | 99.85 | 99.01 | 0.57 | 23.1 | 71.3 | 2 | 0/0 | 0 | 1947 | 168 | 0 |
|
Chip 15
|
A
|
6 | 0 | 99.89 | 99.37 | 0.45 | 25.1 | 75.5 | 6 | 0/0 | 0 | 1966 | 175 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-06-15 | |
| TestTime | Test Time | 15:42 | |
| TestDuration | Duration | 1:28:3 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
