Test Date: 2016-06-15 15:42
Analysis date: 2016-06-15 17:25
Analysis date: 2016-06-15 17:25
M2255 XRayHRQualification
Summary
| Module | Module | M2255 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 57 | |
| BumpBondingDefects | Bump Bonding Defects | 55 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.23 | % |
| Noise | Mean Noise | 160 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
26 | 0 | 99.87 | 99.27 | 0.54 | 31.9 | 94.4 | 26 | 0/0 | 0 | 2019 | 160 | 0 |
|
Chip 1
|
A
|
8 | 0 | 99.84 | 99.03 | 0.61 | 33.1 | 99.2 | 8 | 0/0 | 0 | 2052 | 165 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.24 | 0.4 | 28.5 | 87.0 | 0 | 0/0 | 0 | 1997 | 163 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.31 | 0.5 | 49.8 | 144.9 | 0 | 0/0 | 0 | 2162 | 157 | 0 |
|
Chip 4
|
A
|
6 | 0 | 99.88 | 99.31 | 0.5 | 45.4 | 135.2 | 6 | 0/0 | 0 | 2100 | 152 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.86 | 99.25 | 1.99 | 64.8 | 186.1 | 0 | 0/0 | 0 | 2241 | 157 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.28 | 0.67 | 54.5 | 159.6 | 0 | 0/0 | 0 | 2165 | 156 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.27 | 0.76 | 68.5 | 199.6 | 0 | 0/0 | 0 | 2250 | 163 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.35 | 0.65 | 60.5 | 175.8 | 0 | 0/0 | 0 | 2202 | 156 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.90 | 99.38 | 0.4 | 64.6 | 187.6 | 0 | 0/0 | 0 | 2212 | 161 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.28 | 0.84 | 67.7 | 195.3 | 0 | 0/0 | 0 | 2230 | 155 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.35 | 0.49 | 53.1 | 155.0 | 0 | 0/0 | 0 | 2182 | 161 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.21 | 0.85 | 54.2 | 159.2 | 0 | 0/0 | 0 | 2164 | 167 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.86 | 99.28 | 0.39 | 31.8 | 97.0 | 1 | 0/0 | 0 | 2052 | 167 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.85 | 98.92 | 0.71 | 32.8 | 98.7 | 1 | 0/0 | 0 | 2049 | 164 | 0 |
|
Chip 15
|
A
|
15 | 0 | 99.83 | 98.95 | 0.79 | 32.7 | 97.2 | 13 | 0/0 | 0 | 2031 | 158 | 2 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-06-15 | |
| TestTime | Test Time | 15:42 | |
| TestDuration | Duration | 1:28:3 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
