Module | Module | M2253 | |
Grade | Grade | B | |
ElectricalGrade | Electrical Grade | A | |
IVGrade | IV Grade | B | |
ManualGrade | Manual Grade | None | |
PixelDefects | Pixel Defects - A/B/C | 37 - 16/0/0 | |
DeadPixels | Dead Pixels | 3 | |
AddressProblems | Address Problems | 0 | |
ThresholdDefects | Threshold Defects | 6 | |
MaskDefects | Mask Defects | 0 | |
DeadBumps | Dead Bumps | 27 | |
NoisyPixels | Noise Defects | 0 | |
TrimProblems | Trim Problems | 0 | |
PHGainDefects | PH Gain Defects | 0 | |
PHPar1Defects | PH Parameter1 Defects | 1 |
TestCenter | Test Center | ETH | |
TestDate | Test Date | 2016-06-14 | |
TestTime | Test Time | 11:01 | |
TestDuration | Duration | 1:27:52 | |
TempC | Temparature | 17 | °C |
TBM1 | TBM1 | ok, 0x34 0x64 | |
TBM2 | TBM2 | ok, 0x00 0x64 | |
PxarVersion | pXar | v2.7.5+16 g4df2ad8 | |
DTB_FW | DTB FW | 4.6 | |
ModuleIa | Module Ia | 379.4 | mA |
Noise | Noise | 140.66 | e |
NoiseROCs | Noise grades | 16/0/0 | |
VcalThrWidth | Vcal Thr. Width | 45.62 | e |
VcalThrWidthROCs | Vcal Thr. W. grades | 16/0/0 | |
RelGainWidth | Rel. Gain Width | 0.03 | % |
RelGainWidthROCs | Rel. Gain W. grades | 16/0/0 | |
PedestalSpread | Pedestal Spread | 1218.28 | e |
PedestalSpreadROCs | Ped. Spread grades | 16/0/0 | |
Parameter1 | Parameter1 | 0.70 | |
Parameter1ROCs | Par1 grades | 16/0/0 | |
CurrentAtVoltage150V | I(150 V) | 3.79 | μA |
CurrentVariation | I(150 V) / I(100 V) | 1.44 |
Duration | Duration | 1:27:52 | |
MinCurrent | min. Current | 0.374 | A |
MaxCurrent | max. Current | 0.482 | A |
Duration | Duration | 1:27:52 | |
MinCurrent | min. Current | 0.072 | A |
MaxCurrent | max. Current | 0.383 | A |
ModuleIa | Module Ia | 379.4 | mA |
IanaLossProblems | Iana problems | No | |
Mean | mean | 19.05 | |
Min | min | 18.50 | |
Max | max | 19.30 | |
NROCsNotProgrammable | ROCs not programmable | 0 |
Temperature | Temp. while test | 17.00 +/- 0.06 | °C |
Duration | Duration of test | 1:28:19 |
ROC | Grade | Total | Dead | Mask | Bumps | Trim(Bits) | Address | Noise | Thresh | Gain | Ped | Par1 | Mean noise | Thr [e-] | Thr width | Rel gain width | Ped spread |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Chip 0 |
A
|
7
|
0
|
0
|
7
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
133.54
|
1749 |
44
|
0.034
|
1115
|
Chip 1 |
A
|
2
|
0
|
0
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
142.36
|
1747 |
48
|
0.028
|
1196
|
Chip 2 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
145.61
|
1750 |
45
|
0.031
|
1128
|
Chip 3 |
A
|
3
|
0
|
0
|
3
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
138.61
|
1748 |
46
|
0.028
|
1036
|
Chip 4 |
A
|
3
|
1
|
0
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
138.73
|
1748 |
43
|
0.027
|
1074
|
Chip 5 |
A
|
3
|
0
|
0
|
2
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
143.97
|
1748 |
46
|
0.034
|
1240
|
Chip 6 |
A
|
7
|
1
|
0
|
4
|
0
|
0
|
0
|
1
|
0
|
0
|
1
|
142.38
|
1751 |
48
|
0.031
|
1228
|
Chip 7 |
A
|
5
|
0
|
0
|
5
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
144.52
|
1750 |
44
|
0.033
|
1234
|
Chip 8 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
147.33
|
1746 |
46
|
0.028
|
1342
|
Chip 9 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
140.98
|
1749 |
46
|
0.031
|
1402
|
Chip 10 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
147.47
|
1748 |
46
|
0.030
|
1333
|
Chip 11 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
136.07
|
1748 |
45
|
0.026
|
990
|
Chip 12 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
129.38
|
1750 |
43
|
0.031
|
1521
|
Chip 13 |
A
|
1
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
147.16
|
1750 |
46
|
0.030
|
1164
|
Chip 14 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
133.40
|
1758 |
48
|
0.037
|
1230
|
Chip 15 |
A
|
2
|
0
|
0
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
139.01
|
1748 |
46
|
0.030
|
1259
|
ModifiedGrading | Modified Grading | True | |
GradingParameters_leakageCurrentRatioB | leakageCurrentRatioB | 20 => -111 |
nTBMs | n | 1 | |
TBMType | Type | tbm09c | |
Core0a_basea | Core 0a base a | 0x64 | |
Core0a_basee | Core 0a base e | 0x34 | |
Core0b_basea | Core 0b base a | 0x64 | |
Core0b_basee | Core 0b base e | 0x00 | |
RocDelay_Ch0 | Roc Delay Ch0 | 4 | |
RocDelay_Ch1 | Roc Delay Ch1 | 4 | |
RocDelay_Ch2 | Roc Delay Ch2 | 4 | |
RocDelay_Ch3 | Roc Delay Ch3 | 4 | |
Phase400 | Phase 400 | 5 | |
Phase160 | Phase 160 | 1 |
nCriticals | # Criticals | 0 | |
nErrors | # Errors | 2 | |
nWarnings | # Warnings | 0 | |
channel_0_count | Channel 0 | 2 | |
channel_1_count | Channel 1 | 0 | |
channel_2_count | Channel 2 | 0 | |
channel_3_count | Channel 3 | 0 | |
message_eventid_count | Event ID mismatch | 1 | |
message_tokenchain_count | Token Chain Length | 1 |
