Test Date: 2016-05-12 13:37
Analysis date: 2016-05-26 17:21
Analysis date: 2016-05-26 17:21
M2227 XRayHRQualification
Summary
| Module | Module | M2227 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 16 | |
| BumpBondingDefects | Bump Bonding Defects | 14 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.27 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.87 | 99.30 | 0.47 | 30.3 | 90.4 | 0 | 0/0 | 0 | 1996 | 171 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 98.99 | 0.67 | 26.8 | 83.3 | 0 | 0/0 | 0 | 1976 | 153 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.31 | 0.5 | 27.2 | 83.7 | 0 | 0/0 | 0 | 1958 | 171 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.89 | 99.32 | 0.59 | 51.2 | 148.4 | 0 | 0/0 | 0 | 2130 | 164 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.20 | 0.72 | 52.8 | 153.5 | 0 | 0/0 | 0 | 2127 | 165 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.84 | 99.30 | 0.84 | 64.1 | 183.0 | 0 | 0/0 | 0 | 2208 | 162 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.34 | 0.62 | 61.7 | 178.7 | 0 | 0/0 | 0 | 2167 | 162 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.87 | 99.32 | 0.79 | 63.7 | 183.3 | 1 | 0/0 | 0 | 2191 | 156 | 0 |
|
Chip 8
|
A
|
3 | 0 | 99.87 | 99.30 | 1.14 | 70.5 | 200.7 | 2 | 0/0 | 0 | 2253 | 160 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.37 | 0.68 | 65.2 | 186.2 | 0 | 0/0 | 0 | 2208 | 162 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.36 | 0.45 | 67.7 | 190.9 | 0 | 0/0 | 0 | 2232 | 151 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.85 | 99.22 | 1.14 | 52.4 | 152.3 | 0 | 0/0 | 0 | 2148 | 162 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.87 | 99.23 | 0.73 | 52.7 | 153.1 | 1 | 0/0 | 0 | 2124 | 173 | 0 |
|
Chip 13
|
A
|
3 | 0 | 99.86 | 99.18 | 0.64 | 28.5 | 86.3 | 3 | 0/0 | 0 | 2001 | 169 | 0 |
|
Chip 14
|
A
|
3 | 0 | 99.86 | 99.30 | 1.32 | 32.8 | 97.6 | 2 | 0/0 | 0 | 2031 | 175 | 0 |
|
Chip 15
|
A
|
5 | 0 | 99.87 | 99.29 | 0.41 | 33.6 | 99.1 | 5 | 0/0 | 0 | 2041 | 183 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-05-12 | |
| TestTime | Test Time | 13:37 | |
| TestDuration | Duration | 1:28:17 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
