Test Date: 2016-05-09 10:18
Analysis date: 2016-05-26 17:02
Analysis date: 2016-05-26 17:02
M2224 XRayHRQualification
Summary
| Module | Module | M2224 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.27 | % |
| Noise | Mean Noise | 175 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.87 | 99.30 | 0.51 | 30.9 | 90.9 | 0 | 0/0 | 0 | 1985 | 182 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.25 | 0.66 | 32.8 | 97.5 | 0 | 0/0 | 0 | 2010 | 185 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.07 | 0.71 | 29.3 | 88.3 | 0 | 0/0 | 0 | 1975 | 181 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.85 | 99.24 | 0.93 | 53.8 | 156.1 | 0 | 0/0 | 0 | 2154 | 181 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.35 | 0.6 | 49.3 | 143.2 | 0 | 0/0 | 0 | 2130 | 170 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.86 | 99.32 | 0.66 | 69.0 | 199.0 | 0 | 0/0 | 0 | 2234 | 178 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.86 | 99.28 | 0.81 | 61.2 | 177.9 | 0 | 0/0 | 0 | 2183 | 177 | 1 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.31 | 0.75 | 64.3 | 186.2 | 0 | 0/0 | 0 | 2203 | 174 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.34 | 0.69 | 49.6 | 147.2 | 0 | 0/0 | 0 | 2128 | 166 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.26 | 0.57 | 51.5 | 150.7 | 0 | 0/0 | 0 | 2128 | 168 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.35 | 0.79 | 59.1 | 169.5 | 0 | 0/0 | 0 | 2178 | 169 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.33 | 1.16 | 45.9 | 136.1 | 0 | 0/0 | 0 | 2104 | 168 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.26 | 0.57 | 50.6 | 147.5 | 0 | 0/0 | 0 | 2142 | 176 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.27 | 0.46 | 28.6 | 86.8 | 0 | 0/0 | 0 | 1991 | 183 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.88 | 99.32 | 0.52 | 30.1 | 90.5 | 0 | 0/0 | 0 | 1979 | 171 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.85 | 99.08 | 0.7 | 30.1 | 89.2 | 0 | 0/0 | 0 | 1977 | 173 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-05-09 | |
| TestTime | Test Time | 10:18 | |
| TestDuration | Duration | 1:27:38 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
