Test Date: 2016-05-09 10:18
Analysis date: 2016-05-26 16:56
Analysis date: 2016-05-26 16:56
M2223 XRayHRQualification
Summary
| Module | Module | M2223 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 28 | |
| BumpBondingDefects | Bump Bonding Defects | 27 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.31 | % |
| Noise | Mean Noise | 168 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
4 | 0 | 99.87 | 99.25 | 0.48 | 29.4 | 87.3 | 4 | 0/0 | 0 | 1988 | 169 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.89 | 99.33 | 0.5 | 29.8 | 89.6 | 1 | 0/0 | 0 | 1989 | 168 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.88 | 99.34 | 0.33 | 30.4 | 91.7 | 0 | 0/0 | 0 | 1976 | 180 | 0 |
|
Chip 3
|
A
|
2 | 0 | 99.89 | 99.34 | 0.56 | 52.1 | 149.6 | 2 | 0/0 | 0 | 2149 | 165 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.89 | 99.35 | 0.55 | 54.5 | 157.8 | 0 | 0/0 | 0 | 2132 | 166 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.84 | 99.25 | 3.23 | 64.3 | 182.5 | 0 | 0/0 | 0 | 2203 | 161 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.32 | 1.16 | 63.5 | 182.4 | 0 | 0/0 | 0 | 2203 | 169 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.86 | 99.36 | 0.79 | 69.8 | 199.7 | 1 | 0/0 | 0 | 2256 | 172 | 0 |
|
Chip 8
|
A
|
5 | 0 | 99.88 | 99.39 | 0.6 | 68.4 | 196.1 | 5 | 0/0 | 0 | 2225 | 170 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.88 | 99.35 | 0.73 | 62.3 | 178.9 | 1 | 0/0 | 0 | 2198 | 162 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.87 | 99.31 | 0.88 | 62.6 | 177.9 | 1 | 0/0 | 0 | 2180 | 159 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.89 | 99.33 | 0.64 | 52.0 | 151.1 | 1 | 0/0 | 0 | 2127 | 166 | 0 |
|
Chip 12
|
A
|
7 | 0 | 99.88 | 99.39 | 0.39 | 48.1 | 139.3 | 7 | 0/0 | 0 | 2129 | 167 | 0 |
|
Chip 13
|
A
|
3 | 0 | 99.87 | 99.36 | 0.41 | 26.4 | 80.8 | 3 | 0/0 | 0 | 1971 | 163 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.85 | 99.02 | 0.7 | 30.4 | 91.1 | 1 | 0/0 | 0 | 2020 | 175 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.88 | 99.30 | 0.49 | 29.3 | 86.9 | 0 | 0/0 | 0 | 1978 | 171 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-05-09 | |
| TestTime | Test Time | 10:18 | |
| TestDuration | Duration | 1:27:38 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
