Test Date: 2016-05-09 10:18
Analysis date: 2016-05-26 16:50
Analysis date: 2016-05-26 16:50
M2222 XRayHRQualification
Summary
| Module | Module | M2222 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 159 | |
| BumpBondingDefects | Bump Bonding Defects | 158 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.23 | % |
| Noise | Mean Noise | 167 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
21 | 0 | 99.88 | 99.28 | 0.42 | 22.5 | 67.9 | 21 | 0/0 | 0 | 1925 | 159 | 0 |
|
Chip 1
|
A
|
11 | 0 | 99.88 | 99.35 | 0.42 | 22.6 | 68.8 | 11 | 0/0 | 0 | 1949 | 165 | 0 |
|
Chip 2
|
A
|
21 | 0 | 99.85 | 99.12 | 0.46 | 20.6 | 63.6 | 21 | 0/0 | 0 | 1948 | 165 | 0 |
|
Chip 3
|
A
|
16 | 0 | 99.85 | 99.23 | 1.07 | 35.6 | 105.1 | 16 | 0/0 | 0 | 2065 | 164 | 0 |
|
Chip 4
|
A
|
24 | 0 | 99.88 | 99.34 | 0.49 | 36.8 | 109.7 | 24 | 0/0 | 0 | 2047 | 163 | 0 |
|
Chip 5
|
A
|
21 | 0 | 99.84 | 99.08 | 0.67 | 47.5 | 137.8 | 21 | 0/0 | 0 | 2106 | 167 | 0 |
|
Chip 6
|
A
|
11 | 0 | 99.88 | 99.40 | 0.43 | 48.4 | 142.8 | 11 | 0/0 | 0 | 2123 | 178 | 0 |
|
Chip 7
|
A
|
21 | 0 | 99.88 | 99.36 | 0.59 | 45.1 | 133.6 | 21 | 0/0 | 0 | 2100 | 186 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.86 | 99.08 | 0.72 | 33.9 | 102.6 | 1 | 0/0 | 0 | 2028 | 165 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.88 | 99.36 | 1.1 | 33.6 | 100.8 | 0 | 0/0 | 0 | 2016 | 157 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.08 | 0.71 | 36.4 | 108.4 | 0 | 0/0 | 0 | 2057 | 165 | 0 |
|
Chip 11
|
A
|
11 | 0 | 99.86 | 99.34 | 0.86 | 34.8 | 103.1 | 11 | 0/0 | 0 | 2047 | 174 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.29 | 0.77 | 30.6 | 91.3 | 0 | 0/0 | 0 | 2002 | 166 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.31 | 0.33 | 18.2 | 56.3 | 0 | 0/0 | 0 | 1927 | 170 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.01 | 0.4 | 20.6 | 62.8 | 0 | 0/0 | 0 | 1935 | 166 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 99.09 | 2.65 | 20.2 | 61.0 | 0 | 0/0 | 0 | 1921 | 163 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-05-09 | |
| TestTime | Test Time | 10:18 | |
| TestDuration | Duration | 1:27:38 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
