Test Date: 2016-05-04 10:00
Analysis date: 2016-05-26 16:38
Analysis date: 2016-05-26 16:38
M2220 XRayHRQualification
Summary
| Module | Module | M2220 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 33 | |
| BumpBondingDefects | Bump Bonding Defects | 31 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.32 | % |
| Noise | Mean Noise | 167 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.84 | 99.03 | 0.66 | 30.0 | 88.1 | 3 | 0/0 | 0 | 1996 | 175 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 99.07 | 0.61 | 32.1 | 95.5 | 0 | 0/0 | 0 | 2012 | 176 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.83 | 99.32 | 0.95 | 29.1 | 87.5 | 1 | 0/0 | 0 | 2005 | 185 | 0 |
|
Chip 3
|
A
|
3 | 0 | 99.87 | 99.37 | 0.52 | 49.0 | 141.4 | 3 | 0/0 | 0 | 2117 | 171 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.85 | 99.30 | 1.03 | 54.3 | 157.1 | 0 | 0/0 | 0 | 2143 | 168 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.87 | 99.37 | 1.12 | 58.3 | 166.1 | 1 | 0/0 | 0 | 2185 | 162 | 0 |
|
Chip 6
|
A
|
2 | 0 | 99.87 | 99.36 | 0.92 | 55.0 | 158.7 | 2 | 0/0 | 0 | 2176 | 159 | 0 |
|
Chip 7
|
A
|
5 | 0 | 99.88 | 99.40 | 0.45 | 67.6 | 193.6 | 5 | 0/0 | 0 | 2258 | 173 | 0 |
|
Chip 8
|
A
|
2 | 0 | 99.87 | 99.33 | 0.45 | 63.9 | 182.6 | 0 | 0/0 | 0 | 2127 | 158 | 2 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.36 | 0.39 | 57.9 | 166.5 | 0 | 0/0 | 0 | 2192 | 160 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.39 | 0.87 | 61.0 | 174.5 | 0 | 0/0 | 0 | 2198 | 163 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.89 | 99.38 | 0.47 | 50.9 | 147.3 | 1 | 0/0 | 0 | 2161 | 162 | 0 |
|
Chip 12
|
A
|
6 | 0 | 99.89 | 99.40 | 0.44 | 46.9 | 135.6 | 6 | 0/0 | 0 | 2143 | 160 | 0 |
|
Chip 13
|
A
|
5 | 0 | 99.86 | 99.37 | 0.49 | 26.4 | 80.4 | 5 | 0/0 | 0 | 1994 | 161 | 0 |
|
Chip 14
|
A
|
4 | 0 | 99.89 | 99.36 | 0.46 | 29.8 | 89.2 | 4 | 0/0 | 0 | 2004 | 167 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.88 | 99.33 | 0.43 | 32.1 | 94.0 | 0 | 0/0 | 0 | 2021 | 181 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-05-04 | |
| TestTime | Test Time | 10:00 | |
| TestDuration | Duration | 1:26:36 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 17 | |
| nWarnings | # Warnings | 5 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 5 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 1 | |
| message_readback_count | Readback start marker | 4 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
