Test Date: 2016-05-04 10:00
Analysis date: 2016-05-26 16:32
Analysis date: 2016-05-26 16:32
M2219 XRayHRQualification
Summary
| Module | Module | M2219 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 11/5/0 | |
| PixelDefects | Total Pixel Defects | 484 | |
| BumpBondingDefects | Bump Bonding Defects | 483 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.28 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
13 | 0 | 99.85 | 99.07 | 0.6 | 28.5 | 85.2 | 13 | 0/0 | 0 | 1960 | 171 | 0 |
|
Chip 1
|
B
|
112 | 0 | 99.87 | 99.29 | 2.26 | 28.2 | 85.4 | 111 | 0/0 | 0 | 1990 | 166 | 0 |
|
Chip 2
|
A
|
3 | 0 | 99.87 | 99.34 | 0.47 | 23.6 | 74.2 | 3 | 0/0 | 0 | 1963 | 156 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.34 | 0.57 | 43.3 | 127.9 | 0 | 0/0 | 0 | 2083 | 157 | 0 |
|
Chip 4
|
B
|
77 | 0 | 99.89 | 99.35 | 0.49 | 48.0 | 141.4 | 77 | 0/0 | 0 | 2112 | 173 | 0 |
|
Chip 5
|
B
|
42 | 0 | 99.84 | 99.31 | 1.3 | 62.8 | 181.2 | 42 | 0/0 | 0 | 2222 | 164 | 0 |
|
Chip 6
|
A
|
17 | 0 | 99.88 | 99.36 | 0.48 | 52.3 | 153.6 | 17 | 0/0 | 0 | 2129 | 158 | 0 |
|
Chip 7
|
A
|
3 | 0 | 99.88 | 99.37 | 0.55 | 65.5 | 189.3 | 3 | 0/0 | 0 | 2220 | 163 | 0 |
|
Chip 8
|
B
|
56 | 0 | 99.87 | 99.29 | 0.89 | 60.0 | 172.0 | 56 | 0/0 | 0 | 2199 | 166 | 0 |
|
Chip 9
|
A
|
16 | 0 | 99.87 | 99.31 | 0.48 | 55.9 | 162.5 | 16 | 0/0 | 0 | 2161 | 161 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.31 | 0.66 | 64.0 | 181.9 | 0 | 0/0 | 0 | 2230 | 162 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.88 | 99.33 | 0.68 | 51.4 | 149.4 | 1 | 0/0 | 0 | 2138 | 164 | 0 |
|
Chip 12
|
B
|
92 | 0 | 99.86 | 99.28 | 0.69 | 47.8 | 139.4 | 92 | 0/0 | 0 | 2116 | 171 | 0 |
|
Chip 13
|
A
|
40 | 0 | 99.86 | 99.35 | 0.35 | 27.6 | 84.0 | 40 | 0/0 | 0 | 1997 | 170 | 0 |
|
Chip 14
|
A
|
8 | 0 | 99.88 | 99.25 | 0.58 | 27.7 | 83.8 | 8 | 0/0 | 0 | 1997 | 163 | 0 |
|
Chip 15
|
A
|
4 | 0 | 99.85 | 98.99 | 0.68 | 29.9 | 88.5 | 4 | 0/0 | 0 | 2002 | 172 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-05-04 | |
| TestTime | Test Time | 10:00 | |
| TestDuration | Duration | 1:26:36 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
