Test Date: 2016-04-25 09:19
Analysis date: 2016-05-26 16:07
Analysis date: 2016-05-26 16:07
M2215 XRayHRQualification
Summary
| Module | Module | M2215 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 12 | |
| BumpBondingDefects | Bump Bonding Defects | 10 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.19 | % |
| Noise | Mean Noise | 168 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.88 | 99.06 | 0.81 | 23.6 | 70.1 | 0 | 0/0 | 0 | 1962 | 173 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 99.03 | 0.45 | 23.4 | 70.3 | 0 | 0/0 | 0 | 1961 | 167 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 98.98 | 0.4 | 18.7 | 57.6 | 0 | 0/0 | 0 | 1924 | 167 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.26 | 0.61 | 34.7 | 102.0 | 0 | 0/0 | 0 | 2051 | 167 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.89 | 99.32 | 0.39 | 35.7 | 106.1 | 0 | 0/0 | 0 | 2037 | 171 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.17 | 0.77 | 40.4 | 118.8 | 0 | 0/0 | 0 | 2059 | 159 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.34 | 0.44 | 42.6 | 124.5 | 0 | 0/0 | 0 | 2100 | 171 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.88 | 99.30 | 0.46 | 39.0 | 115.6 | 1 | 0/0 | 0 | 2047 | 167 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.84 | 99.30 | 1.93 | 42.2 | 124.1 | 0 | 0/0 | 0 | 2083 | 165 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.35 | 0.37 | 41.4 | 122.7 | 0 | 0/0 | 0 | 2066 | 163 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.37 | 0.54 | 46.7 | 135.6 | 0 | 0/0 | 0 | 2137 | 171 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.26 | 0.83 | 40.6 | 119.4 | 0 | 0/0 | 0 | 2112 | 172 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.84 | 99.01 | 0.64 | 34.4 | 102.6 | 0 | 0/0 | 0 | 2031 | 168 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.86 | 99.24 | 0.38 | 20.6 | 63.4 | 0 | 0/0 | 0 | 1911 | 166 | 1 |
|
Chip 14
|
A
|
2 | 0 | 99.87 | 99.10 | 0.5 | 23.8 | 71.9 | 2 | 0/0 | 0 | 1963 | 164 | 0 |
|
Chip 15
|
A
|
7 | 0 | 99.85 | 99.01 | 0.54 | 25.6 | 76.0 | 7 | 0/0 | 0 | 1975 | 167 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-25 | |
| TestTime | Test Time | 09:19 | |
| TestDuration | Duration | 1:26:52 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
