Test Date: 2016-04-25 09:19
Analysis date: 2016-05-26 16:01
Analysis date: 2016-05-26 16:01
M2214 XRayHRQualification
Summary
| Module | Module | M2214 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 17 | |
| BumpBondingDefects | Bump Bonding Defects | 17 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.28 | % |
| Noise | Mean Noise | 166 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.87 | 99.30 | 0.65 | 31.8 | 93.4 | 0 | 0/0 | 0 | 2011 | 181 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.29 | 0.51 | 29.5 | 88.0 | 0 | 0/0 | 0 | 1996 | 173 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.86 | 99.03 | 0.48 | 25.1 | 76.7 | 1 | 0/0 | 0 | 1982 | 164 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.36 | 0.48 | 55.2 | 158.1 | 0 | 0/0 | 0 | 2189 | 165 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.89 | 99.34 | 0.5 | 46.4 | 135.9 | 0 | 0/0 | 0 | 2125 | 162 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.88 | 99.35 | 0.78 | 63.4 | 178.2 | 1 | 0/0 | 0 | 2222 | 166 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.33 | 0.55 | 57.9 | 166.6 | 0 | 0/0 | 0 | 2191 | 156 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.87 | 99.30 | 1.24 | 60.4 | 172.0 | 1 | 0/0 | 0 | 2209 | 165 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.34 | 0.67 | 66.5 | 189.7 | 0 | 0/0 | 0 | 2235 | 164 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.34 | 0.66 | 62.4 | 178.8 | 0 | 0/0 | 0 | 2213 | 161 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.33 | 0.43 | 59.4 | 170.1 | 0 | 0/0 | 0 | 2174 | 161 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.32 | 0.69 | 54.2 | 157.2 | 0 | 0/0 | 0 | 2177 | 166 | 0 |
|
Chip 12
|
A
|
7 | 0 | 99.89 | 99.36 | 0.57 | 53.0 | 152.3 | 7 | 0/0 | 0 | 2171 | 163 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.00 | 0.93 | 30.3 | 91.1 | 0 | 0/0 | 0 | 2030 | 166 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.88 | 99.26 | 0.54 | 30.8 | 91.9 | 0 | 0/0 | 0 | 1998 | 167 | 0 |
|
Chip 15
|
A
|
7 | 0 | 99.85 | 99.17 | 0.74 | 33.2 | 97.2 | 7 | 0/0 | 0 | 1994 | 182 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-25 | |
| TestTime | Test Time | 09:19 | |
| TestDuration | Duration | 1:26:52 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
