Test Date: 2016-04-25 09:19
Analysis date: 2016-05-26 15:55
Analysis date: 2016-05-26 15:55
M2213 XRayHRQualification
Summary
| Module | Module | M2213 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 76 | |
| BumpBondingDefects | Bump Bonding Defects | 74 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.28 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
19 | 0 | 99.89 | 99.34 | 0.44 | 30.0 | 88.5 | 19 | 0/0 | 0 | 1997 | 168 | 0 |
|
Chip 1
|
A
|
12 | 0 | 99.85 | 99.05 | 0.53 | 31.2 | 93.0 | 12 | 0/0 | 0 | 2009 | 165 | 0 |
|
Chip 2
|
A
|
5 | 0 | 99.85 | 99.05 | 0.55 | 27.9 | 84.6 | 5 | 0/0 | 0 | 1978 | 168 | 0 |
|
Chip 3
|
A
|
5 | 0 | 99.87 | 99.32 | 0.65 | 48.7 | 140.8 | 4 | 0/0 | 0 | 2091 | 162 | 1 |
|
Chip 4
|
A
|
2 | 0 | 99.85 | 99.26 | 1.35 | 54.0 | 155.8 | 2 | 0/0 | 0 | 2154 | 162 | 0 |
|
Chip 5
|
A
|
4 | 0 | 99.83 | 99.35 | 3.77 | 57.3 | 164.0 | 3 | 0/0 | 0 | 2171 | 161 | 0 |
|
Chip 6
|
A
|
2 | 0 | 99.88 | 99.38 | 0.68 | 53.2 | 155.6 | 2 | 0/0 | 0 | 2160 | 162 | 0 |
|
Chip 7
|
A
|
7 | 0 | 99.86 | 99.36 | 0.57 | 68.3 | 196.8 | 7 | 0/0 | 0 | 2223 | 169 | 0 |
|
Chip 8
|
A
|
4 | 0 | 99.87 | 99.31 | 1.41 | 57.2 | 165.2 | 4 | 0/0 | 0 | 2177 | 165 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.38 | 0.58 | 57.1 | 164.6 | 0 | 0/0 | 0 | 2180 | 164 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.89 | 99.33 | 0.43 | 57.4 | 163.6 | 0 | 0/0 | 0 | 2184 | 156 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.37 | 0.61 | 52.6 | 152.9 | 0 | 0/0 | 0 | 2156 | 166 | 0 |
|
Chip 12
|
A
|
2 | 0 | 99.86 | 99.17 | 0.87 | 51.8 | 149.7 | 2 | 0/0 | 0 | 2146 | 174 | 0 |
|
Chip 13
|
A
|
3 | 0 | 99.86 | 99.34 | 0.58 | 27.0 | 82.1 | 3 | 0/0 | 0 | 1980 | 166 | 0 |
|
Chip 14
|
A
|
4 | 0 | 99.86 | 99.21 | 0.55 | 28.9 | 87.1 | 4 | 0/0 | 0 | 1988 | 163 | 0 |
|
Chip 15
|
A
|
7 | 0 | 99.87 | 99.21 | 0.64 | 30.0 | 88.5 | 7 | 0/0 | 0 | 2004 | 164 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-25 | |
| TestTime | Test Time | 09:19 | |
| TestDuration | Duration | 1:26:52 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
