Test Date: 2016-04-20 09:33
Analysis date: 2016-05-26 15:36
Analysis date: 2016-05-26 15:36
M2210 XRayHRQualification
Summary
| Module | Module | M2210 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 34 | |
| BumpBondingDefects | Bump Bonding Defects | 32 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.30 | % |
| Noise | Mean Noise | 162 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
5 | 0 | 99.88 | 99.33 | 0.55 | 28.4 | 85.6 | 4 | 0/0 | 0 | 1977 | 171 | 1 |
|
Chip 1
|
A
|
3 | 0 | 99.86 | 99.09 | 0.63 | 29.6 | 90.2 | 3 | 0/0 | 0 | 2001 | 169 | 0 |
|
Chip 2
|
A
|
3 | 0 | 99.87 | 99.35 | 0.43 | 25.2 | 78.5 | 3 | 0/0 | 0 | 1959 | 156 | 0 |
|
Chip 3
|
A
|
2 | 0 | 99.87 | 99.25 | 0.54 | 43.0 | 128.2 | 2 | 0/0 | 0 | 2075 | 157 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.86 | 99.28 | 1.46 | 47.4 | 140.7 | 1 | 0/0 | 0 | 2108 | 165 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.89 | 99.36 | 0.56 | 60.0 | 173.1 | 1 | 0/0 | 0 | 2201 | 161 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.35 | 0.55 | 62.5 | 181.9 | 0 | 0/0 | 0 | 2186 | 170 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.90 | 99.35 | 0.58 | 59.0 | 172.4 | 1 | 0/0 | 0 | 2161 | 157 | 0 |
|
Chip 8
|
A
|
4 | 0 | 99.87 | 99.32 | 0.8 | 62.1 | 180.1 | 4 | 0/0 | 0 | 2196 | 159 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.35 | 0.42 | 57.6 | 166.4 | 0 | 0/0 | 0 | 2173 | 159 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.39 | 0.42 | 56.2 | 163.3 | 0 | 0/0 | 0 | 2167 | 154 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.89 | 99.37 | 0.5 | 49.5 | 144.7 | 0 | 0/0 | 0 | 2140 | 163 | 0 |
|
Chip 12
|
A
|
2 | 0 | 99.88 | 99.35 | 0.54 | 43.2 | 128.1 | 2 | 0/0 | 0 | 2083 | 160 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.88 | 99.30 | 0.51 | 26.8 | 82.0 | 0 | 0/0 | 0 | 1998 | 166 | 0 |
|
Chip 14
|
A
|
3 | 0 | 99.88 | 99.35 | 0.41 | 27.6 | 84.8 | 3 | 0/0 | 0 | 1994 | 164 | 0 |
|
Chip 15
|
A
|
8 | 0 | 99.85 | 99.01 | 0.55 | 26.2 | 80.4 | 8 | 0/0 | 0 | 1948 | 165 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-20 | |
| TestTime | Test Time | 09:33 | |
| TestDuration | Duration | 1:22:5 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 34 | |
| nWarnings | # Warnings | 10 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 5 | |
| channel_3_count | Channel 3 | 5 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_readback_count | Readback start marker | 8 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
