Test Date: 2016-04-19 10:16
Analysis date: 2016-05-26 15:20
Analysis date: 2016-05-26 15:20
M2208 XRayHRQualification
Summary
| Module | Module | M2208 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 10/6/0 | |
| PixelDefects | Total Pixel Defects | 615 | |
| BumpBondingDefects | Bump Bonding Defects | 615 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.36 | % |
| Noise | Mean Noise | 167 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
B
|
45 | 0 | 99.88 | 99.33 | 0.5 | 30.5 | 89.6 | 45 | 0/0 | 0 | 1998 | 169 | 0 |
|
Chip 1
|
A
|
24 | 0 | 99.88 | 99.26 | 0.39 | 29.4 | 87.8 | 24 | 0/0 | 0 | 2016 | 162 | 0 |
|
Chip 2
|
A
|
35 | 0 | 99.87 | 99.27 | 0.87 | 25.5 | 78.0 | 35 | 0/0 | 0 | 1988 | 166 | 0 |
|
Chip 3
|
B
|
46 | 0 | 99.90 | 99.35 | 0.55 | 47.5 | 137.6 | 46 | 0/0 | 0 | 2137 | 171 | 0 |
|
Chip 4
|
A
|
14 | 0 | 99.89 | 99.29 | 0.5 | 49.2 | 143.5 | 14 | 0/0 | 0 | 2149 | 164 | 0 |
|
Chip 5
|
A
|
39 | 0 | 99.89 | 99.43 | 0.45 | 57.7 | 165.0 | 39 | 0/0 | 0 | 2193 | 162 | 0 |
|
Chip 6
|
A
|
19 | 0 | 99.86 | 99.38 | 0.51 | 61.4 | 178.2 | 19 | 0/0 | 0 | 2220 | 169 | 0 |
|
Chip 7
|
B
|
61 | 0 | 99.86 | 99.40 | 0.62 | 63.9 | 186.7 | 61 | 0/0 | 0 | 2221 | 176 | 0 |
|
Chip 8
|
B
|
60 | 0 | 99.87 | 99.36 | 0.51 | 55.2 | 161.3 | 60 | 0/0 | 0 | 2155 | 159 | 0 |
|
Chip 9
|
A
|
38 | 0 | 99.88 | 99.36 | 0.75 | 56.4 | 163.4 | 38 | 0/0 | 0 | 2178 | 163 | 0 |
|
Chip 10
|
A
|
30 | 0 | 99.88 | 99.43 | 0.47 | 60.0 | 171.7 | 30 | 0/0 | 0 | 2203 | 158 | 0 |
|
Chip 11
|
B
|
48 | 0 | 99.87 | 99.37 | 0.58 | 54.0 | 157.3 | 48 | 0/0 | 0 | 2186 | 174 | 0 |
|
Chip 12
|
A
|
33 | 0 | 99.89 | 99.37 | 0.59 | 45.2 | 132.9 | 33 | 0/0 | 0 | 2097 | 165 | 0 |
|
Chip 13
|
A
|
30 | 0 | 99.88 | 99.40 | 0.44 | 28.4 | 85.8 | 30 | 0/0 | 0 | 1994 | 175 | 0 |
|
Chip 14
|
B
|
52 | 0 | 99.88 | 99.33 | 0.55 | 31.0 | 92.6 | 52 | 0/0 | 0 | 2025 | 170 | 0 |
|
Chip 15
|
A
|
41 | 0 | 99.89 | 99.39 | 0.46 | 31.1 | 90.9 | 41 | 0/0 | 0 | 2019 | 167 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-19 | |
| TestTime | Test Time | 10:16 | |
| TestDuration | Duration | 1:24:5 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
