Test Date: 2016-04-19 10:16
Analysis date: 2016-05-26 15:13
Analysis date: 2016-05-26 15:13
M2207 XRayHRQualification
Summary
| Module | Module | M2207 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 162 | |
| BumpBondingDefects | Bump Bonding Defects | 161 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.31 | % |
| Noise | Mean Noise | 163 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
6 | 0 | 99.85 | 99.03 | 0.76 | 29.1 | 85.8 | 6 | 0/0 | 0 | 1992 | 173 | 0 |
|
Chip 1
|
A
|
18 | 0 | 99.89 | 99.39 | 0.74 | 30.8 | 91.6 | 18 | 0/0 | 0 | 2017 | 166 | 0 |
|
Chip 2
|
A
|
6 | 0 | 99.87 | 99.28 | 0.31 | 29.6 | 90.0 | 6 | 0/0 | 0 | 1976 | 178 | 0 |
|
Chip 3
|
A
|
8 | 0 | 99.86 | 99.36 | 0.73 | 49.6 | 143.5 | 8 | 0/0 | 0 | 2143 | 163 | 0 |
|
Chip 4
|
A
|
5 | 0 | 99.87 | 99.34 | 0.5 | 44.9 | 133.0 | 5 | 0/0 | 0 | 2106 | 157 | 0 |
|
Chip 5
|
A
|
4 | 0 | 99.89 | 99.38 | 0.45 | 63.1 | 178.4 | 4 | 0/0 | 0 | 2213 | 161 | 0 |
|
Chip 6
|
A
|
7 | 0 | 99.89 | 99.33 | 0.53 | 55.7 | 161.7 | 7 | 0/0 | 0 | 2159 | 158 | 0 |
|
Chip 7
|
A
|
25 | 0 | 99.89 | 99.36 | 0.64 | 59.9 | 173.5 | 25 | 0/0 | 0 | 2174 | 155 | 0 |
|
Chip 8
|
A
|
6 | 0 | 99.88 | 99.33 | 0.59 | 61.8 | 178.3 | 6 | 0/0 | 0 | 2194 | 161 | 0 |
|
Chip 9
|
A
|
3 | 0 | 99.89 | 99.39 | 0.61 | 56.2 | 162.3 | 3 | 0/0 | 0 | 2168 | 155 | 0 |
|
Chip 10
|
A
|
7 | 0 | 99.89 | 99.35 | 0.57 | 59.2 | 168.9 | 7 | 0/0 | 0 | 2151 | 158 | 0 |
|
Chip 11
|
A
|
11 | 0 | 99.90 | 99.35 | 0.57 | 50.5 | 145.7 | 11 | 0/0 | 0 | 2145 | 162 | 0 |
|
Chip 12
|
A
|
4 | 0 | 99.85 | 99.31 | 0.69 | 46.0 | 133.8 | 4 | 0/0 | 0 | 2108 | 165 | 0 |
|
Chip 13
|
A
|
8 | 0 | 99.86 | 99.17 | 0.54 | 27.5 | 83.3 | 8 | 0/0 | 0 | 1999 | 166 | 0 |
|
Chip 14
|
A
|
16 | 0 | 99.86 | 99.30 | 0.47 | 26.4 | 80.3 | 15 | 0/0 | 0 | 1982 | 154 | 0 |
|
Chip 15
|
A
|
28 | 0 | 99.88 | 99.32 | 0.45 | 29.7 | 87.7 | 28 | 0/0 | 0 | 1953 | 179 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-19 | |
| TestTime | Test Time | 10:16 | |
| TestDuration | Duration | 1:24:5 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
