Test Date: 2016-04-19 10:16
Analysis date: 2016-05-26 15:07
Analysis date: 2016-05-26 15:07
M2206 XRayHRQualification
Summary
| Module | Module | M2206 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 55 | |
| BumpBondingDefects | Bump Bonding Defects | 55 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.27 | % |
| Noise | Mean Noise | 168 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
8 | 0 | 99.87 | 99.12 | 0.51 | 22.8 | 68.3 | 8 | 0/0 | 0 | 1927 | 166 | 0 |
|
Chip 1
|
A
|
5 | 0 | 99.89 | 99.38 | 0.29 | 23.8 | 71.9 | 5 | 0/0 | 0 | 1967 | 173 | 0 |
|
Chip 2
|
A
|
4 | 0 | 99.85 | 99.11 | 0.7 | 22.4 | 68.2 | 4 | 0/0 | 0 | 1952 | 169 | 0 |
|
Chip 3
|
A
|
8 | 0 | 99.90 | 99.34 | 0.51 | 41.5 | 121.2 | 8 | 0/0 | 0 | 2070 | 179 | 0 |
|
Chip 4
|
A
|
3 | 0 | 99.89 | 99.34 | 0.51 | 38.4 | 113.5 | 3 | 0/0 | 0 | 2058 | 163 | 0 |
|
Chip 5
|
A
|
6 | 0 | 99.89 | 99.39 | 0.53 | 51.6 | 148.0 | 6 | 0/0 | 0 | 2175 | 166 | 0 |
|
Chip 6
|
A
|
5 | 0 | 99.90 | 99.39 | 0.38 | 48.1 | 139.6 | 5 | 0/0 | 0 | 2113 | 167 | 0 |
|
Chip 7
|
A
|
11 | 0 | 99.88 | 99.39 | 0.89 | 52.9 | 152.0 | 11 | 0/0 | 0 | 2145 | 166 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.89 | 99.36 | 0.54 | 48.2 | 139.6 | 1 | 0/0 | 0 | 2124 | 170 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.89 | 99.41 | 0.36 | 43.9 | 126.9 | 1 | 0/0 | 0 | 2097 | 169 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.89 | 99.38 | 0.4 | 45.1 | 130.4 | 1 | 0/0 | 0 | 2097 | 165 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.85 | 99.03 | 0.52 | 38.7 | 113.9 | 1 | 0/0 | 0 | 2061 | 172 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.30 | 0.67 | 31.1 | 93.3 | 0 | 0/0 | 0 | 2003 | 163 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.05 | 0.38 | 20.1 | 61.4 | 0 | 0/0 | 0 | 1946 | 170 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.88 | 99.30 | 0.29 | 20.9 | 63.5 | 0 | 0/0 | 0 | 1945 | 168 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.86 | 98.98 | 0.46 | 19.9 | 60.3 | 1 | 0/0 | 0 | 1921 | 170 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-19 | |
| TestTime | Test Time | 10:16 | |
| TestDuration | Duration | 1:24:5 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
