Test Date: 2016-04-14 11:21
Analysis date: 2016-05-26 14:54
X-ray Calibration - Spectrum
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
46.0555 |
|
| medianSlope |
median Slope |
45.78 |
|
| minSlope |
min Slope |
42.276 |
|
| maxSlope |
max Slope |
49.863 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-38.8234375 |
|
| medianOffset |
median Offset |
-40.288 |
|
| minOffset |
min Offset |
-228.266 |
|
| maxOffset |
max Offset |
145.451 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
3.69575 |
|
| medianchi2 |
median chi2 |
2.4185 |
|
| minchi2 |
min chi2 |
0.017 |
|
| maxchi2 |
max chi2 |
25.301 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
44.7 e- / Vcal
|
0.1 e- / Vcal
|
-228.3 e-
|
18.5 e-
|
|
1
|
45.7 e- / Vcal
|
0.1 e- / Vcal
|
-57.4 e-
|
19.1 e-
|
|
2
|
43.7 e- / Vcal
|
0.2 e- / Vcal
|
1.5 e-
|
20.4 e-
|
|
3
|
49.9 e- / Vcal
|
0.1 e- / Vcal
|
78.6 e-
|
5.7 e-
|
|
4
|
43.8 e- / Vcal
|
0.1 e- / Vcal
|
145.5 e-
|
8.2 e-
|
|
5
|
42.3 e- / Vcal
|
0.0 e- / Vcal
|
-3.5 e-
|
5.7 e-
|
|
6
|
48.3 e- / Vcal
|
0.1 e- / Vcal
|
-169.6 e-
|
6.7 e-
|
|
7
|
45.8 e- / Vcal
|
0.2 e- / Vcal
|
-85.0 e-
|
22.0 e-
|
|
8
|
45.8 e- / Vcal
|
0.1 e- / Vcal
|
-46.1 e-
|
18.3 e-
|
|
9
|
46.9 e- / Vcal
|
0.1 e- / Vcal
|
-172.9 e-
|
18.7 e-
|
|
10
|
45.8 e- / Vcal
|
0.1 e- / Vcal
|
-34.4 e-
|
16.4 e-
|
|
11
|
48.3 e- / Vcal
|
0.1 e- / Vcal
|
-75.1 e-
|
17.0 e-
|
|
12
|
47.3 e- / Vcal
|
0.1 e- / Vcal
|
55.3 e-
|
6.8 e-
|
|
13
|
44.5 e- / Vcal
|
0.2 e- / Vcal
|
57.4 e-
|
20.6 e-
|
|
14
|
48.4 e- / Vcal
|
0.2 e- / Vcal
|
-157.8 e-
|
19.6 e-
|
|
15
|
45.7 e- / Vcal
|
0.2 e- / Vcal
|
70.9 e-
|
19.2 e-
|
|
Average
|
46.1 e- / Vcal
|
|
-38.8 e-
|
|
|
Median
|
91.6 e- / Vcal
|
|
-131.2 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
