Test Date: 2016-04-14 11:21
Analysis date: 2016-05-26 14:54
Analysis date: 2016-05-26 14:54
M2204 XRayHRQualification
Summary
| Module | Module | M2204 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 58 | |
| BumpBondingDefects | Bump Bonding Defects | 57 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.24 | % |
| Noise | Mean Noise | 170 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.86 | 99.08 | 0.53 | 25.4 | 75.4 | 3 | 0/0 | 0 | 1958 | 175 | 0 |
|
Chip 1
|
A
|
5 | 0 | 99.86 | 99.03 | 0.61 | 26.7 | 79.8 | 5 | 0/0 | 0 | 1989 | 174 | 0 |
|
Chip 2
|
A
|
4 | 0 | 99.85 | 99.11 | 0.53 | 22.7 | 69.3 | 4 | 0/0 | 0 | 1943 | 174 | 0 |
|
Chip 3
|
A
|
2 | 0 | 99.85 | 99.04 | 0.56 | 37.7 | 110.9 | 1 | 0/0 | 0 | 2007 | 163 | 1 |
|
Chip 4
|
A
|
5 | 0 | 99.88 | 99.32 | 0.61 | 41.5 | 122.6 | 5 | 0/0 | 0 | 2084 | 171 | 0 |
|
Chip 5
|
A
|
4 | 0 | 99.87 | 99.44 | 0.49 | 52.7 | 151.7 | 4 | 0/0 | 0 | 2156 | 176 | 0 |
|
Chip 6
|
A
|
2 | 0 | 99.90 | 99.37 | 0.39 | 48.4 | 140.9 | 2 | 0/0 | 0 | 2125 | 165 | 0 |
|
Chip 7
|
A
|
8 | 0 | 99.88 | 99.42 | 0.44 | 52.9 | 153.4 | 8 | 0/0 | 0 | 2146 | 171 | 0 |
|
Chip 8
|
A
|
13 | 0 | 99.90 | 99.40 | 0.51 | 42.7 | 125.6 | 13 | 0/0 | 0 | 2085 | 172 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.30 | 0.57 | 41.9 | 123.0 | 0 | 0/0 | 0 | 2094 | 169 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.40 | 0.61 | 42.6 | 123.4 | 0 | 0/0 | 0 | 2102 | 164 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.36 | 0.64 | 34.4 | 102.5 | 0 | 0/0 | 0 | 2034 | 164 | 0 |
|
Chip 12
|
A
|
2 | 0 | 99.87 | 99.16 | 0.71 | 32.3 | 96.5 | 2 | 0/0 | 0 | 2002 | 165 | 0 |
|
Chip 13
|
A
|
4 | 0 | 99.87 | 99.12 | 0.33 | 20.2 | 61.6 | 4 | 0/0 | 0 | 1940 | 169 | 0 |
|
Chip 14
|
A
|
2 | 0 | 99.86 | 98.99 | 0.51 | 23.0 | 69.3 | 2 | 0/0 | 0 | 1958 | 170 | 0 |
|
Chip 15
|
A
|
4 | 0 | 99.89 | 99.35 | 0.37 | 23.3 | 69.5 | 4 | 0/0 | 0 | 1953 | 175 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-14 | |
| TestTime | Test Time | 11:21 | |
| TestDuration | Duration | 1:25:14 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
