Test Date: 2016-04-14 09:29
Analysis date: 2016-05-26 14:48
Analysis date: 2016-05-26 14:48
M2203 XRayHRQualification
Summary
| Module | Module | M2203 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 158 | |
| BumpBondingDefects | Bump Bonding Defects | 153 | |
| NoisyPixels | Noisy Pixels | 4 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.26 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
22 | 0 | 99.86 | 99.10 | 0.38 | 21.2 | 65.1 | 22 | 0/0 | 0 | 1941 | 173 | 0 |
|
Chip 1
|
A
|
11 | 0 | 99.85 | 99.05 | 0.54 | 23.1 | 71.3 | 10 | 0/0 | 0 | 1916 | 174 | 1 |
|
Chip 2
|
A
|
18 | 0 | 99.86 | 99.09 | 0.33 | 17.6 | 55.4 | 18 | 0/0 | 0 | 1904 | 162 | 0 |
|
Chip 3
|
A
|
10 | 0 | 99.87 | 99.30 | 0.55 | 38.0 | 112.5 | 10 | 0/0 | 0 | 2064 | 171 | 0 |
|
Chip 4
|
A
|
8 | 0 | 99.88 | 99.36 | 0.67 | 36.5 | 109.0 | 8 | 0/0 | 0 | 2045 | 166 | 0 |
|
Chip 5
|
A
|
13 | 0 | 99.88 | 99.28 | 0.56 | 43.2 | 126.1 | 13 | 0/0 | 0 | 2080 | 164 | 0 |
|
Chip 6
|
A
|
11 | 0 | 99.87 | 99.31 | 0.65 | 40.9 | 120.9 | 11 | 0/0 | 0 | 2070 | 162 | 0 |
|
Chip 7
|
A
|
18 | 0 | 99.88 | 99.37 | 0.48 | 45.7 | 133.3 | 18 | 0/0 | 0 | 2102 | 165 | 0 |
|
Chip 8
|
A
|
6 | 0 | 99.88 | 99.32 | 1.01 | 48.9 | 142.1 | 6 | 0/0 | 0 | 2125 | 162 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.85 | 99.30 | 1.35 | 51.7 | 146.9 | 0 | 0/0 | 0 | 2144 | 159 | 0 |
|
Chip 10
|
A
|
3 | 0 | 99.88 | 99.40 | 0.52 | 49.8 | 143.4 | 3 | 0/0 | 0 | 2128 | 159 | 0 |
|
Chip 11
|
A
|
3 | 0 | 99.87 | 99.35 | 0.5 | 44.0 | 128.9 | 3 | 0/0 | 0 | 2097 | 165 | 0 |
|
Chip 12
|
A
|
6 | 0 | 99.86 | 99.18 | 0.58 | 40.9 | 120.5 | 4 | 0/0 | 0 | 2015 | 172 | 2 |
|
Chip 13
|
A
|
2 | 0 | 99.87 | 99.37 | 0.36 | 21.2 | 65.7 | 2 | 0/0 | 0 | 1954 | 156 | 0 |
|
Chip 14
|
A
|
5 | 0 | 99.85 | 99.11 | 0.68 | 26.7 | 81.0 | 5 | 0/0 | 0 | 1992 | 169 | 0 |
|
Chip 15
|
A
|
21 | 0 | 99.88 | 99.34 | 0.46 | 23.9 | 72.6 | 20 | 0/0 | 0 | 1926 | 167 | 1 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-14 | |
| TestTime | Test Time | 09:29 | |
| TestDuration | Duration | 1:27:20 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
