Test Date: 2016-04-12 09:31
Analysis date: 2016-06-23 11:47
Analysis date: 2016-06-23 11:47
M2196 XRayHRQualification
Summary
| Module | Module | M2196 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 150 | |
| BumpBondingDefects | Bump Bonding Defects | 150 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.18 | % |
| Noise | Mean Noise | 171 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.88 | 99.28 | 0.32 | 20.9 | 64.3 | 3 | 0/0 | 0 | 1926 | 166 | 0 |
|
Chip 1
|
A
|
2 | 0 | 99.84 | 99.00 | 0.77 | 23.2 | 71.0 | 2 | 0/0 | 0 | 1967 | 166 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.01 | 0.58 | 19.9 | 61.9 | 0 | 0/0 | 0 | 1903 | 165 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.28 | 0.48 | 41.1 | 120.6 | 0 | 0/0 | 0 | 2084 | 176 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.78 | 98.94 | 1.87 | 41.0 | 121.0 | 0 | 0/0 | 0 | 2054 | 174 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.32 | 0.63 | 53.1 | 153.1 | 0 | 0/0 | 0 | 2139 | 170 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.36 | 0.57 | 52.7 | 153.9 | 0 | 0/0 | 0 | 2154 | 178 | 0 |
|
Chip 7
|
A
|
2 | 0 | 99.86 | 99.28 | 0.8 | 52.3 | 151.0 | 2 | 0/0 | 0 | 2147 | 171 | 0 |
|
Chip 8
|
A
|
9 | 0 | 99.83 | 99.09 | 0.85 | 45.1 | 131.5 | 9 | 0/0 | 0 | 2106 | 166 | 0 |
|
Chip 9
|
A
|
10 | 0 | 99.88 | 99.33 | 0.49 | 45.6 | 132.9 | 10 | 0/0 | 0 | 2107 | 173 | 0 |
|
Chip 10
|
A
|
7 | 0 | 99.86 | 99.19 | 0.64 | 40.5 | 119.0 | 7 | 0/0 | 0 | 2060 | 165 | 0 |
|
Chip 11
|
A
|
13 | 0 | 99.89 | 99.31 | 0.45 | 37.9 | 113.0 | 13 | 0/0 | 0 | 2038 | 182 | 0 |
|
Chip 12
|
A
|
4 | 0 | 99.86 | 99.03 | 0.68 | 34.2 | 102.6 | 4 | 0/0 | 0 | 2026 | 174 | 0 |
|
Chip 13
|
A
|
22 | 0 | 99.86 | 99.28 | 0.44 | 18.5 | 57.6 | 22 | 0/0 | 0 | 1925 | 160 | 0 |
|
Chip 14
|
A
|
16 | 0 | 99.86 | 99.11 | 0.35 | 20.5 | 63.3 | 16 | 0/0 | 0 | 1941 | 169 | 0 |
|
Chip 15
|
B
|
62 | 0 | 99.86 | 99.07 | 0.36 | 20.4 | 62.2 | 62 | 0/0 | 0 | 1940 | 176 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-12 | |
| TestTime | Test Time | 09:31 | |
| TestDuration | Duration | 1:27:0 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
