Test Date: 2016-04-11 17:49
Analysis date: 2016-05-26 13:49
Analysis date: 2016-05-26 13:49
M2193 XRayHRQualification
Summary
| Module | Module | M2193 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 72 | |
| BumpBondingDefects | Bump Bonding Defects | 70 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.28 | % |
| Noise | Mean Noise | 170 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.85 | 99.06 | 0.71 | 32.1 | 93.5 | 1 | 0/0 | 0 | 1983 | 182 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.88 | 99.30 | 0.55 | 30.6 | 91.2 | 0 | 0/0 | 0 | 2001 | 175 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.03 | 0.5 | 28.5 | 85.8 | 0 | 0/0 | 0 | 2003 | 167 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.35 | 0.66 | 49.7 | 143.2 | 0 | 0/0 | 0 | 2118 | 176 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.30 | 0.76 | 49.9 | 145.0 | 0 | 0/0 | 0 | 2128 | 167 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.40 | 0.53 | 56.8 | 161.7 | 0 | 0/0 | 0 | 2180 | 161 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.34 | 0.72 | 60.2 | 173.8 | 0 | 0/0 | 0 | 2203 | 172 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.90 | 99.36 | 0.7 | 57.1 | 165.6 | 0 | 0/0 | 0 | 2154 | 165 | 0 |
|
Chip 8
|
A
|
9 | 0 | 99.89 | 99.34 | 0.75 | 60.3 | 174.1 | 9 | 0/0 | 0 | 2168 | 158 | 0 |
|
Chip 9
|
A
|
3 | 0 | 99.88 | 99.38 | 0.46 | 57.3 | 164.7 | 2 | 0/0 | 0 | 2147 | 159 | 1 |
|
Chip 10
|
A
|
4 | 0 | 99.88 | 99.45 | 0.49 | 66.5 | 189.0 | 4 | 0/0 | 0 | 2249 | 171 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.88 | 99.35 | 0.6 | 59.1 | 171.9 | 1 | 0/0 | 0 | 2163 | 183 | 0 |
|
Chip 12
|
A
|
2 | 0 | 99.87 | 99.15 | 0.81 | 50.5 | 146.1 | 2 | 0/0 | 0 | 2111 | 171 | 0 |
|
Chip 13
|
A
|
4 | 0 | 99.85 | 99.03 | 0.9 | 31.1 | 93.9 | 3 | 0/0 | 0 | 1970 | 187 | 1 |
|
Chip 14
|
A
|
13 | 0 | 99.86 | 99.28 | 0.97 | 32.1 | 95.5 | 13 | 0/0 | 0 | 2003 | 174 | 0 |
|
Chip 15
|
A
|
35 | 0 | 99.88 | 99.33 | 0.34 | 28.9 | 85.8 | 35 | 0/0 | 0 | 1995 | 160 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-11 | |
| TestTime | Test Time | 17:49 | |
| TestDuration | Duration | 1:27:5 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
