Test Date: 2016-04-11 17:49
Analysis date: 2016-05-26 13:36
Analysis date: 2016-05-26 13:36
M2191 XRayHRQualification
Summary
| Module | Module | M2191 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 12 | |
| BumpBondingDefects | Bump Bonding Defects | 12 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.35 | % |
| Noise | Mean Noise | 173 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.88 | 99.32 | 0.43 | 23.8 | 71.0 | 0 | 0/0 | 0 | 1956 | 171 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.88 | 99.34 | 0.4 | 24.5 | 73.7 | 1 | 0/0 | 0 | 1952 | 167 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.39 | 0.47 | 22.2 | 67.8 | 0 | 0/0 | 0 | 1955 | 172 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.34 | 0.47 | 40.2 | 117.0 | 0 | 0/0 | 0 | 2082 | 170 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.35 | 0.6 | 39.2 | 115.6 | 0 | 0/0 | 0 | 2056 | 169 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.37 | 0.39 | 43.9 | 128.3 | 0 | 0/0 | 0 | 2088 | 169 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.89 | 99.35 | 0.43 | 41.4 | 122.4 | 0 | 0/0 | 0 | 2053 | 168 | 0 |
|
Chip 7
|
A
|
2 | 0 | 99.88 | 99.38 | 0.54 | 46.6 | 137.3 | 2 | 0/0 | 0 | 2116 | 168 | 0 |
|
Chip 8
|
A
|
5 | 0 | 99.87 | 99.41 | 0.66 | 48.0 | 139.8 | 5 | 0/0 | 0 | 2115 | 182 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.42 | 0.36 | 39.2 | 115.9 | 0 | 0/0 | 0 | 2037 | 174 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.37 | 0.51 | 45.1 | 130.8 | 0 | 0/0 | 0 | 2104 | 170 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.30 | 0.47 | 37.0 | 109.7 | 0 | 0/0 | 0 | 2064 | 171 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.40 | 0.36 | 34.2 | 100.8 | 0 | 0/0 | 0 | 2046 | 176 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.14 | 0.41 | 21.4 | 65.2 | 0 | 0/0 | 0 | 1930 | 190 | 0 |
|
Chip 14
|
A
|
3 | 0 | 99.87 | 99.34 | 0.36 | 22.6 | 68.2 | 3 | 0/0 | 0 | 1953 | 174 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.88 | 99.35 | 0.38 | 21.9 | 65.3 | 1 | 0/0 | 0 | 1953 | 171 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-11 | |
| TestTime | Test Time | 17:49 | |
| TestDuration | Duration | 1:27:5 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
