Test Date: 2016-03-23 15:37
Analysis date: 2016-05-26 12:38
Analysis date: 2016-05-26 12:38
M2182 XRayHRQualification
Summary
| Module | Module | M2182 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 149 | |
| BumpBondingDefects | Bump Bonding Defects | 146 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.33 | % |
| Noise | Mean Noise | 166 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
8 | 0 | 99.87 | 99.32 | 0.52 | 33.1 | 96.6 | 8 | 0/0 | 0 | 2015 | 175 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.85 | 99.07 | 0.83 | 32.6 | 96.3 | 1 | 0/0 | 0 | 2019 | 167 | 0 |
|
Chip 2
|
A
|
7 | 0 | 99.87 | 99.32 | 0.57 | 28.0 | 85.0 | 7 | 0/0 | 0 | 1943 | 167 | 0 |
|
Chip 3
|
B
|
97 | 0 | 99.89 | 99.38 | 0.51 | 51.2 | 145.9 | 97 | 0/0 | 0 | 2142 | 162 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.88 | 99.38 | 0.59 | 53.7 | 153.1 | 1 | 0/0 | 0 | 2169 | 161 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.88 | 99.38 | 0.49 | 65.5 | 185.5 | 1 | 0/0 | 0 | 2207 | 157 | 0 |
|
Chip 6
|
A
|
3 | 0 | 99.89 | 99.37 | 0.6 | 65.1 | 185.7 | 3 | 0/0 | 0 | 2203 | 162 | 0 |
|
Chip 7
|
A
|
8 | 0 | 99.88 | 99.43 | 0.63 | 73.6 | 208.4 | 8 | 0/0 | 0 | 2267 | 171 | 0 |
|
Chip 8
|
A
|
4 | 0 | 99.88 | 99.38 | 0.54 | 65.7 | 187.3 | 4 | 0/0 | 0 | 2186 | 161 | 0 |
|
Chip 9
|
A
|
8 | 0 | 99.88 | 99.39 | 0.82 | 59.5 | 170.6 | 8 | 0/0 | 0 | 2186 | 160 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.85 | 99.32 | 1.1 | 70.0 | 196.2 | 1 | 0/0 | 0 | 2251 | 167 | 0 |
|
Chip 11
|
A
|
3 | 0 | 99.89 | 99.36 | 0.58 | 58.1 | 166.0 | 2 | 0/0 | 0 | 2184 | 169 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.87 | 99.31 | 0.82 | 53.0 | 152.0 | 1 | 0/0 | 0 | 2119 | 172 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.87 | 99.31 | 0.72 | 27.6 | 83.3 | 0 | 0/0 | 0 | 1976 | 161 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.87 | 99.25 | 0.66 | 30.9 | 91.8 | 0 | 0/0 | 0 | 1996 | 174 | 0 |
|
Chip 15
|
A
|
5 | 0 | 99.88 | 99.29 | 0.57 | 28.1 | 83.6 | 4 | 0/0 | 0 | 1972 | 167 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-03-23 | |
| TestTime | Test Time | 15:37 | |
| TestDuration | Duration | 1:25:17 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
