Test Date: 2016-02-26 19:12
Analysis date: 2016-05-26 12:12
Analysis date: 2016-05-26 12:12
M2176 XRayHRQualification
Summary
| Module | Module | M2176 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 0/14/2 | |
| PixelDefects | Total Pixel Defects | 1981 | |
| BumpBondingDefects | Bump Bonding Defects | 1981 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 2 | |
| Efficiency | Efficiency 50/120 | 99.88/99.33 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
C
|
288 | 0 | 99.89 | 99.36 | 0.33 | 19.2 | 58.0 | 288 | 0/0 | 1 | 1925 | 156 | 0 |
|
Chip 1
|
B
|
123 | 0 | 99.88 | 99.30 | 0.38 | 21.6 | 65.5 | 123 | 0/0 | 0 | 1932 | 154 | 0 |
|
Chip 2
|
B
|
98 | 0 | 99.87 | 99.38 | 0.36 | 20.1 | 61.1 | 98 | 0/0 | 0 | 1938 | 168 | 0 |
|
Chip 3
|
B
|
97 | 0 | 99.90 | 99.41 | 0.53 | 38.9 | 113.7 | 97 | 0/0 | 0 | 2041 | 175 | 0 |
|
Chip 4
|
B
|
79 | 0 | 99.87 | 99.39 | 0.46 | 42.8 | 125.4 | 79 | 0/0 | 0 | 2090 | 173 | 0 |
|
Chip 5
|
B
|
79 | 0 | 99.89 | 99.37 | 0.6 | 48.2 | 138.8 | 79 | 0/0 | 0 | 2112 | 159 | 0 |
|
Chip 6
|
B
|
72 | 0 | 99.88 | 99.41 | 0.39 | 44.5 | 129.3 | 72 | 0/0 | 0 | 2079 | 168 | 0 |
|
Chip 7
|
B
|
122 | 0 | 99.90 | 99.44 | 0.38 | 48.5 | 140.0 | 122 | 0/0 | 0 | 2129 | 168 | 0 |
|
Chip 8
|
B
|
148 | 0 | 99.89 | 99.40 | 0.62 | 50.8 | 146.3 | 148 | 0/0 | 0 | 2128 | 165 | 0 |
|
Chip 9
|
B
|
91 | 0 | 99.88 | 99.39 | 0.65 | 54.9 | 158.2 | 91 | 0/0 | 0 | 2174 | 168 | 0 |
|
Chip 10
|
B
|
111 | 0 | 99.88 | 99.41 | 0.46 | 54.2 | 154.9 | 111 | 0/0 | 0 | 2134 | 159 | 0 |
|
Chip 11
|
B
|
98 | 0 | 99.88 | 99.37 | 0.45 | 47.6 | 137.9 | 98 | 0/0 | 0 | 2120 | 169 | 0 |
|
Chip 12
|
B
|
101 | 0 | 99.87 | 99.19 | 0.54 | 37.8 | 110.9 | 101 | 0/0 | 0 | 2015 | 166 | 0 |
|
Chip 13
|
B
|
125 | 0 | 99.84 | 99.11 | 0.6 | 22.5 | 67.7 | 125 | 0/0 | 0 | 1956 | 156 | 0 |
|
Chip 14
|
B
|
110 | 0 | 99.88 | 99.35 | 0.47 | 27.4 | 81.7 | 110 | 0/0 | 0 | 1988 | 180 | 0 |
|
Chip 15
|
C
|
239 | 0 | 99.83 | 99.02 | 0.71 | 22.1 | 65.8 | 239 | 0/0 | 1 | 1926 | 153 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-26 | |
| TestTime | Test Time | 19:12 | |
| TestDuration | Duration | 1:25:54 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
