Test Date: 2016-02-26 19:12
Analysis date: 2016-05-26 11:58
Analysis date: 2016-05-26 11:58
M2174 XRayHRQualification
Summary
| Module | Module | M2174 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 169 | |
| BumpBondingDefects | Bump Bonding Defects | 165 | |
| NoisyPixels | Noisy Pixels | 4 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.35 | % |
| Noise | Mean Noise | 164 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
34 | 0 | 99.85 | 99.11 | 0.63 | 28.8 | 85.4 | 34 | 0/0 | 0 | 1970 | 160 | 0 |
|
Chip 1
|
A
|
9 | 0 | 99.88 | 99.37 | 0.59 | 34.9 | 103.1 | 7 | 0/0 | 0 | 1967 | 184 | 2 |
|
Chip 2
|
A
|
1 | 0 | 99.89 | 99.36 | 0.45 | 31.0 | 93.7 | 1 | 0/0 | 0 | 1947 | 178 | 0 |
|
Chip 3
|
A
|
3 | 0 | 99.87 | 99.42 | 0.5 | 57.3 | 165.8 | 3 | 0/0 | 0 | 2172 | 177 | 0 |
|
Chip 4
|
A
|
14 | 0 | 99.86 | 99.43 | 0.6 | 55.8 | 161.9 | 14 | 0/0 | 0 | 2168 | 175 | 0 |
|
Chip 5
|
A
|
6 | 0 | 99.88 | 99.44 | 0.5 | 59.0 | 169.1 | 6 | 0/0 | 0 | 2158 | 160 | 0 |
|
Chip 6
|
A
|
10 | 0 | 99.87 | 99.40 | 0.6 | 57.2 | 166.5 | 10 | 0/0 | 0 | 2143 | 163 | 0 |
|
Chip 7
|
A
|
19 | 0 | 99.88 | 99.40 | 0.49 | 57.1 | 166.5 | 19 | 0/0 | 0 | 2140 | 153 | 0 |
|
Chip 8
|
A
|
4 | 0 | 99.88 | 99.41 | 0.46 | 57.6 | 167.0 | 4 | 0/0 | 0 | 2166 | 160 | 0 |
|
Chip 9
|
A
|
7 | 0 | 99.90 | 99.40 | 0.69 | 55.5 | 161.7 | 7 | 0/0 | 0 | 2159 | 159 | 0 |
|
Chip 10
|
A
|
7 | 0 | 99.88 | 99.40 | 0.53 | 60.8 | 173.0 | 7 | 0/0 | 0 | 2190 | 158 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.15 | 0.77 | 48.3 | 140.3 | 0 | 0/0 | 0 | 2139 | 159 | 0 |
|
Chip 12
|
A
|
6 | 0 | 99.87 | 99.40 | 0.42 | 48.3 | 139.9 | 6 | 0/0 | 0 | 2131 | 162 | 0 |
|
Chip 13
|
A
|
18 | 0 | 99.85 | 99.11 | 0.61 | 26.7 | 80.7 | 17 | 0/0 | 0 | 1947 | 156 | 1 |
|
Chip 14
|
A
|
7 | 0 | 99.88 | 99.39 | 0.63 | 32.4 | 95.7 | 6 | 0/0 | 0 | 1975 | 164 | 1 |
|
Chip 15
|
A
|
24 | 0 | 99.89 | 99.38 | 0.58 | 30.6 | 89.5 | 24 | 0/0 | 0 | 1986 | 165 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-26 | |
| TestTime | Test Time | 19:12 | |
| TestDuration | Duration | 1:25:54 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
