Test Date: 2016-02-26 10:52
Analysis date: 2016-05-26 11:26
Analysis date: 2016-05-26 11:26
M2169 XRayHRQualification
Summary
| Module | Module | M2169 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 12/4/0 | |
| PixelDefects | Total Pixel Defects | 464 | |
| BumpBondingDefects | Bump Bonding Defects | 462 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.27 | % |
| Noise | Mean Noise | 166 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
B
|
48 | 0 | 99.86 | 99.07 | 0.53 | 21.7 | 65.6 | 48 | 0/0 | 0 | 1931 | 157 | 0 |
|
Chip 1
|
A
|
33 | 0 | 99.85 | 99.08 | 0.69 | 22.6 | 68.9 | 33 | 0/0 | 0 | 1946 | 162 | 0 |
|
Chip 2
|
A
|
18 | 0 | 99.85 | 99.12 | 0.71 | 21.0 | 64.8 | 18 | 0/0 | 0 | 1919 | 167 | 0 |
|
Chip 3
|
A
|
13 | 0 | 99.87 | 99.33 | 0.46 | 41.5 | 121.7 | 13 | 0/0 | 0 | 2078 | 175 | 0 |
|
Chip 4
|
A
|
16 | 0 | 99.89 | 99.38 | 0.45 | 38.0 | 112.6 | 16 | 0/0 | 0 | 2039 | 162 | 0 |
|
Chip 5
|
A
|
11 | 0 | 99.87 | 99.35 | 0.62 | 52.4 | 151.7 | 11 | 0/0 | 0 | 2120 | 174 | 0 |
|
Chip 6
|
A
|
12 | 0 | 99.86 | 99.23 | 0.86 | 48.4 | 140.8 | 12 | 0/0 | 0 | 2122 | 168 | 0 |
|
Chip 7
|
A
|
23 | 0 | 99.89 | 99.39 | 0.51 | 48.2 | 140.7 | 23 | 0/0 | 0 | 2124 | 166 | 0 |
|
Chip 8
|
A
|
15 | 0 | 99.88 | 99.39 | 0.58 | 47.7 | 138.9 | 15 | 0/0 | 0 | 2103 | 173 | 0 |
|
Chip 9
|
A
|
13 | 0 | 99.88 | 99.37 | 0.55 | 40.8 | 119.3 | 13 | 0/0 | 0 | 2071 | 168 | 0 |
|
Chip 10
|
A
|
39 | 0 | 99.89 | 99.43 | 0.52 | 46.8 | 135.4 | 38 | 0/0 | 0 | 2109 | 171 | 1 |
|
Chip 11
|
A
|
41 | 0 | 99.89 | 99.39 | 0.67 | 34.6 | 102.7 | 41 | 0/0 | 0 | 2032 | 165 | 0 |
|
Chip 12
|
A
|
23 | 0 | 99.89 | 99.39 | 0.57 | 32.7 | 96.9 | 22 | 0/0 | 0 | 1957 | 168 | 1 |
|
Chip 13
|
B
|
47 | 0 | 99.87 | 99.29 | 0.29 | 17.9 | 55.3 | 47 | 0/0 | 0 | 1927 | 163 | 0 |
|
Chip 14
|
B
|
55 | 0 | 99.87 | 99.06 | 0.46 | 19.8 | 60.6 | 55 | 0/0 | 0 | 1917 | 156 | 0 |
|
Chip 15
|
B
|
57 | 0 | 99.83 | 99.03 | 0.46 | 20.0 | 60.5 | 57 | 0/0 | 0 | 1917 | 163 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-26 | |
| TestTime | Test Time | 10:52 | |
| TestDuration | Duration | 1:27:53 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
