Test Date: 2016-02-25 10:07
Analysis date: 2016-05-26 11:19
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
47.821375 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
47.821375 |
|
| medianSlope |
median Slope |
48.075 |
|
| minSlope |
min Slope |
44.713 |
|
| maxSlope |
max Slope |
50.387 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-90.2313125 |
|
| medianOffset |
median Offset |
-94.0115 |
|
| minOffset |
min Offset |
-247.802 |
|
| maxOffset |
max Offset |
53.918 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
2.627625 |
|
| medianchi2 |
median chi2 |
0.855 |
|
| minchi2 |
min chi2 |
0.01 |
|
| maxchi2 |
max chi2 |
13.597 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
47.7 e- / Vcal
|
0.1 e- / Vcal
|
-90.5 e-
|
18.1 e-
|
|
1
|
50.4 e- / Vcal
|
0.2 e- / Vcal
|
-161.7 e-
|
17.4 e-
|
|
2
|
48.7 e- / Vcal
|
0.2 e- / Vcal
|
20.7 e-
|
19.4 e-
|
|
3
|
45.1 e- / Vcal
|
0.2 e- / Vcal
|
-3.2 e-
|
19.3 e-
|
|
4
|
47.8 e- / Vcal
|
0.1 e- / Vcal
|
-51.1 e-
|
7.0 e-
|
|
5
|
49.5 e- / Vcal
|
0.1 e- / Vcal
|
-117.8 e-
|
6.0 e-
|
|
6
|
50.0 e- / Vcal
|
0.2 e- / Vcal
|
34.2 e-
|
19.2 e-
|
|
7
|
48.2 e- / Vcal
|
0.1 e- / Vcal
|
-77.6 e-
|
17.5 e-
|
|
8
|
49.2 e- / Vcal
|
0.1 e- / Vcal
|
-97.5 e-
|
16.8 e-
|
|
9
|
48.0 e- / Vcal
|
0.1 e- / Vcal
|
-110.6 e-
|
17.5 e-
|
|
10
|
44.7 e- / Vcal
|
0.1 e- / Vcal
|
-247.8 e-
|
18.5 e-
|
|
11
|
47.9 e- / Vcal
|
0.1 e- / Vcal
|
-70.9 e-
|
17.5 e-
|
|
12
|
48.5 e- / Vcal
|
0.1 e- / Vcal
|
-196.2 e-
|
7.4 e-
|
|
13
|
45.7 e- / Vcal
|
0.2 e- / Vcal
|
53.9 e-
|
19.3 e-
|
|
14
|
48.3 e- / Vcal
|
0.1 e- / Vcal
|
-204.2 e-
|
7.3 e-
|
|
15
|
45.5 e- / Vcal
|
0.1 e- / Vcal
|
-123.4 e-
|
11.1 e-
|
|
Average
|
47.8 e- / Vcal
|
|
-90.2 e-
|
|
|
Median
|
97.4 e- / Vcal
|
|
-175.1 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
